Katoite

Ca3Al2(OH)12
IMA status
  • Approved
IMA symbol
Kto
Discovered
1982
IMA approved
1982
Also known as
  • C3AH6
  • IMA1982-080a
  • Katoiet
  • +1 more

Where it forms, where it's found

Type locality
Campomorto Quarry
  1. Pietra Massa Locality
  2. Montalto di Castro
  3. Viterbo Province
  4. Lazio
  5. Italy

42.3800°, 11.6510°

19recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Colourless
Streak
White
Density
3.013 g/cm³

Optical

Optical type
Isotropic
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Space group
Ia3d
Cell parameters
a = 12.24095(8) Å
Z
8
Comment

Synthetic katoite has a = 12.5731(2) A (Lager et al., 2002).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
50.75%
20CaCalciumCalcium340.078120.234
31.78%
13AlAluminiumAluminium226.98253.964
14.27%
1HHydrogenHydrogen121.00812.096
3.20%
Total378.282100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • S

Synonyms

  • C3AH6
  • IMA1982-080a
  • Katoiet
  • Tricalcium Aluminate Hydrate

In other languages

German
IMA 1982-080 · Katoit
Italian
Katoite
Japanese
加藤柘榴石

Classification

Strunz
10th ed.

4.FF

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FFHydroxides with OH, without H2O; various polyhedraGroup
  • 4.FFKatoiteSpecies
Dana
8th ed.

51.04.3d.02

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.04Insular SiO4 Groups Only with cations in [6] and >[6] coordinationType
  • 51.04.3d— unnamed intermediate level —Group
  • 51.04.3d.02KatoiteSpecies
CIM

16.9.17

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.17KatoiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1967Cohen-Addad, C., Ducros, P., Bertaut, E. F. (1967) Étude de la substitution du groupement SiO4 par (OH)4 dans les composés Al2Ca3(OH)12 et Al2Ca3(SiO4)2,16(OH)3,36 de type grenat. Acta Crystallographica, 23 (2). 220-230 doi:10.1107/s0365110x67002518DOI: 10.1107/s0365110x67002518
  2. 1968Foreman, Dennis W. (1968) Neutron and X‐Ray Diffraction Study of Ca3Al2(O4D4)3, a Garnetoid. The Journal of Chemical Physics, 48 (7) 3037-3041 doi:10.1063/1.1669569DOI: 10.1063/1.1669569
  3. 1984Passaglia, Elio, Rinaldi, Romano (1984) Katoite, a new member of the Ca3Al2(SiO4)3-Ca3Al2(OH)12 series and a new nomenclature for the hydrogrossular group of minerals. Bulletin de Minéralogie, 107 (5) 605-618 doi:10.3406/bulmi.1984.7804DOI: 10.3406/bulmi.1984.7804
  4. 1985Sacerdoti, Michele, Passaglia, Elio (1985) The crystal structure of katoite and implications within the hydrogrossular group of minerals. Bulletin de Minéralogie, 108 (1) 1-8 doi:10.3406/bulmi.1985.7852DOI: 10.3406/bulmi.1985.7852
  5. 1985Dunn, Pete J., Fleischer, Michael, Langley, Richard H., Shigley, James E., Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (7-8) 871-881
