Kawazulite

Bi2Te2Se
IMA status
  • Approved
IMA symbol
Kaw
Discovered
1970
Also known as
  • IMA1968-014
  • Kawazuliet
  • Kawazulit

Where it forms, where it's found

Geological setting

Tellurium deposit

Type locality
Kawazu mine (Rendaiji mine
  1. Rendaizi mine)
  2. Rendaiji
  3. Shimoda City
  4. Shizuoka Prefecture
  5. Japan

34.6994°, 138.9222°

48recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver to tin-white
Streak
Light steel gray
Tenacity
flexible
Cleavage
Perfect

(0001)

Density
8.08 g/cm³

Optical

Pleochroism
Visible

Pinkish creamy white to white with a creamy tint

Anisotropism
strong: brownish-gray to gray
Bireflectance
Weak to moderate.
Tropism
Anisotropic
Reflectance R%
(45.8,50.6) 400, (47.7,52.0) 440, (49.6,54.3) 480, (50.9,56.0) 520, (51.7,56.6) 560, (52.2,56.8) 600, (52.3,56.6) 640, (52.1,56.3) 680, (51.9,56.2) 700
Reflected-light panel
50.5 %anisotropic · dual curve
Specimen sRGB 253, 176, 94
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak to moderate.
Anisotropism
strong: brownish-gray to gray

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 4.24 Å · c = 29.66 Å
Z
3
Morphology

Thin foils

Type-locality form

Very thin foils up to 4 mm across, with a maximum thickness of 50 microns.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth2208.980417.960
55.57%
52TeTelluriumTellurium2127.600255.200
33.93%
34SeSeleniumSelenium178.97178.971
10.50%
Total752.131100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • S

Synonyms

  • IMA1968-014
  • Kawazuliet
  • Kawazulit

In other languages

German
IMA 1968-014 · Kawazulith
Italian
Kawazulite
Japanese
河津鉱
Russian
Кавацулит

Classification

Strunz
10th ed.

2.DC.05

  • 2Sulfides and SulfosaltsClass
  • 2.DMetal Sulfides, M: S = 3 :4 and 2:3Division
  • 2.DCVariable M:SGroup
  • 2.DC.05KawazuliteSpecies
Dana
8th ed.

02.11.07.05

  • 02SulfidesClass
  • 02.11AmBnXp, with (m+n):p = 2:3Type
  • 02.11.07Tetradymite Group (Trigonal: R-3m)Group
  • 02.11.07.05KawazuliteSpecies
CIM

3.7.34

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.7Sulphides etc. of V, As, Sb and BiGroup
  • 3.7.34KawazuliteSpecies

Group, growth & confusion

In the same group
19 members

Literature, links & citation

Citations
  1. 1963Nakajima, Seizo (1963) The crystal structure of Bi2Te3−xSex. Journal of Physics and Chemistry of Solids, 24. 479-485 doi:10.1016/0022-3697(63)90207-5DOI: 10.1016/0022-3697(63)90207-5
  2. 1970Kato, A. (1970) Kawazulite Bi2Te2S. in Introduction to Japanese Minerals, Geological Survey of Japan: 39: 87-88.
  3. 1972Fleischer, Michael (1972) New Mineral Names. American Mineralogist, 57 (7-8) 1311-1317
  4. 1981Miller, R. (1981) Kawazulite Bi2Te2Se, related bismuth minerals and selenian covellite from the Northwest Territories. The Canadian Mineralogist, 19 (2) 341-348
  5. 1995Shimizu, M. (1995) Kawazulite and unnamed Bi3(Te,Se,S)4 in Ag-Bi-Te-Se-S mineralization from the Suttsu mine, Hokkaido, Japan. Neues Jahrbuch für Mineralogie, Abhandlungen: 169: 305-308.
