Keiviite-(Yb)

Yb2Si2O7
IMA status
  • Approved
IMA symbol
Kvi-Yb
Also known as
  • IMA1982-065
  • Keiviiet-(Yb)
  • Keivyite-(Yb)

Where it forms, where it's found

Geological setting

Microcline bearing pegmatites.

Type locality
Ploskaya Mountain
  1. Western Keivy Massif
  2. Keivy Mountains
  3. Lovozersky District
  4. Murmansk Oblast
  5. Russia

67.6333°, 36.7000°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Colourless
Streak
White
Cleavage
Perfect

perfect on (110), imperfect on (001)

Density
5.95 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 58°
Refractive index
1.723 – 1.768
Surface relief
High
Principal indices
nα 1.723 · nβ 1.758 · nγ 1.768
Dispersion
r < v strong
Extinction
Z = b; X ∧ c = 3°-5°; Y ∧ a = 7°-8°.
UV response
Faint green cathodoluminescence.
Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 6.840(2) Å · b = 8.916(2) Å · c = 4.745(1) Å
Cell angles
β = 102.11(3) °
Ratio a:b:c
1 : 1.304 : 0.694
Z
2
Morphology

Elongated platy and prismatic crystals.

Twinning

Polysynthetic - common.

Type-locality form

Single crystals and intergrowths 0.1-0.8 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
70YbYtterbiumYtterbium2173.045346.090
67.30%
8OOxygenOxygen715.999111.993
21.78%
14SiSiliconSilicon228.08556.170
10.92%
Total514.253100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-065
  • Keiviiet-(Yb)
  • Keivyite-(Yb)

In other languages

German
IMA 1982-065 · Keiviit-(Yb)
Italian
Keiviite- · Keiviite-(Yb)

Classification

Strunz
10th ed.

9.BC.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BCSi2O7 groups, without non-tetrahedral anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BC.05Keiviite-(Yb)Species
Dana
8th ed.

55.02.1a.03

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.02Si2O7 Groups, Generally with no Additional Anions with cations in [6] coordinationType
  • 55.02.1a— unnamed intermediate level —Group
  • 55.02.1a.03Keiviite-(Yb)Species
CIM

14.8.3

  • 14Silicates not Containing AluminumClass
  • 14.8Silicates of Group III metals other than AlGroup
  • 14.8.3Keiviite-(Yb)Species

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1983Voloshin, A.V., Pakhomovsky, Y.A., Tyusheva, F.N. (1983) Keiviite Yb2Si2O7 - a new ytterbium silicate from amazonitic pegmatites of the Kola Peninsula. Mineralogiceskij Zhurnal: 5: 94-99.
  2. 1984Dunn, Pete J.; Cabri, Louis J.; Ferraiolo, James A.; Grice, Joel Do.; Jambor, John L.; Mueller, Wolfgang; Shigley, James E.; Puziewicz, Jacek; Vanko, David A. (1984) New mineral names. American Mineralogist, 69 (11-12). 1190-1196
  3. 1986Yakubovich, O.V., Simonov, M.A., Voloshin, A.V., Pakhomovskii, Y.A. (1986) Crystal structure of keivite Yb2[Si2O7]. Soviet Physics - Doklady: 31: 930-932.
  4. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
  5. 1988Anonymous (1988) Errata. American Mineralogist: 73(1-2): 200.
