Thortveitite

Sc2Si2O7
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tvt
Discovered
1911

Where it forms, where it's found

Geological setting

Granite pegmatite.

Type locality
Ljosland 04 (Thortveitittgruva)
  1. Knipan (Knipane)
  2. Ljosland
  3. Iveland
  4. Agder
  5. Norway

58.4983°, 7.9556°

68recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Greyish-green · black · grey · blue · yellow · brown
Streak
White
Tenacity
brittle
Fracture
Irregular/Uneven · Conchoidal
Density
3.27 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 65° · 2V calc = 64°
Refractive index
1.756 – 1.809
Surface relief
High
Principal indices
nα 1.756 · nβ 1.793 · nγ 1.809
Pleochroism
Visible

X = deep green; Y = Z = brownish yellow in thick grains.

Dispersion
distinct to strong
Extinction
X ∧ c = 5°.
Notes

Absorption: X >= Y = Z.

Michel-Lévy diagramhighlighted lineδ = 0.0530
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]530 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation530 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 6.65 Å · b = 8.61 Å · c = 4.68 Å
Cell angles
β = 102.2 °
Ratio a:b:c
1 : 1.295 : 0.704
Twinning

Common: twinning axis normal to (110), twinning plane (110).

Type-locality form

Crystals to >25 cm long and 4 cm thick. In radial rosettes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
43.40%
21ScScandiumScandium244.95689.912
34.84%
14SiSiliconSilicon228.08556.170
21.76%
Total258.075100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Zr
  • Hf
  • Al
  • Fe
  • Mn
  • Mg
  • Ca
  • Ce
  • TR

In other languages

French
Thortveitite
German
Thortveitit
Spanish
Thortveitita
Italian
Thortveitite
Portuguese
thortveitita
Japanese
ソーベタイト · トルトバイタイト
Chinese
鈧釔石 · 钪钇石
Simplified Chinese
钪钇石
Traditional Chinese
鈧釔石
Russian
Тортвейтит
Arabic
ثورتفيتيت
Hindi
थोर्थवेटाइट

Classification

Strunz
10th ed.

9.BC.05

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BCSi2O7 groups, without non-tetrahedral anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BC.05ThortveititeSpecies
Dana
8th ed.

55.02.1a.04

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.02Si2O7 Groups, Generally with no Additional Anions with cations in [6] coordinationType
  • 55.02.1a— unnamed intermediate level —Group
  • 55.02.1a.04ThortveititeSpecies
CIM

14.8.5

  • 14Silicates not Containing AluminumClass
  • 14.8Silicates of Group III metals other than AlGroup
  • 14.8.5ThortveititeSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1911Schetelig, Jakob (1911) Über Thortveitit, ein neues Mineral. Vorläufige Mitteilung. Centralblatt für Mineralogie, Geologie und Paläontologie, 1911. 721-726
  2. 1920Lacroix, A. (1920) Sur l'existance a Madagascar d'un silicate de scandium et d'yttrium, la thortveitite. Comptes rendus hebdomadaires des séances de l'Académie des sciences, 171, 421-423.
  3. 1922Wherry, E.T. (1922) New minerals: redefinition of species. American Mineralogist: 7: 194-196.
  4. 1922Schetelig, Jakob (1922) Thortveitit, Gadolinit, Kainosit und Orthit, in Die Mineralien der südnorwegischen Granitpegmatitgänge. II. Silikate der seltenen Erde (Y-reihe und Ce-reihe). Videnskapsselskapet i Kristiania Skrifter - I Matematisk-naturvidenskabelig klasse, 1922 (1). 49-138
  5. 1922Schetelig, Jakob (1922) Thortveitite. A silicate of scandium (Sc,Y)2Si207. Norsk Geologisk Tidsskrift [Norwegian Journal of Geology], 6 (3-4) 233-244
