Krausite

KFe3+(SO4)2 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ksi
Discovered
1931
Also known as
  • Krausiet

Where it forms, where it's found

Geological setting

Secondary mineral in sulfate bearing chert.

Oxidation material on pyrite bearing dumps.

Type locality
Sulphur Hole (Sulfur Hole
  1. Sulphur pit)
  2. Calico
  3. Calico District (Daggett District
  4. Calico-Daggett area)
  5. Calico Mts (Calico Hills)
  6. San Bernardino County
  7. California
  8. USA

34.9500°, -116.8167°

25recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Pale lemon yellow · yellowish green · gray · colourless to pale yellow in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (001); Good on (100)

Density
2.84 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75°
Refractive index
1.588 – 1.722
Surface relief
High
Principal indices
nα 1.588 · nβ 1.65 · nγ 1.722
Birefringence
0.034
Pleochroism
Visible

X = Colourless Y = Pale yellow Z = Pale yellow

Dispersion
relatively strong
Extinction
Z=b, Y^c = -35°
UV response
Not fluorescent
Notes

2V large

Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/m
Cell parameters
a = 7.91 Å · b = 5.15 Å · c = 8.99 Å
Cell angles
β = 102.75 °
Ratio a:b:c
1 : 0.651 : 1.137
Z
2
Morphology

Commonly earthy to finely granular. Crystals may be short prismatic [001]; also equant to tabular (001). Larger crystals tend to be rough and opaque, smaller ones brilliant and clear.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
47.20%
16SSulfurSulfur232.06064.120
21.02%
26FeIronIron155.84555.845
18.30%
19KPotassiumPotassium139.09839.098
12.82%
1HHydrogenHydrogen21.0082.016
0.66%
Total305.070100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Krausiet

In other languages

German
Krausit
Italian
Krausite

Classification

Strunz
10th ed.

7.CC.05

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CCWith medium-sized and large cationsGroup
  • 7.CC.05KrausiteSpecies
Dana
8th ed.

29.05.01.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.05AB(XO4)2·xH2OType
  • 29.05.01— unnamed intermediate level —Group
  • 29.05.01.01KrausiteSpecies
CIM

25.11.7

  • 25SulphatesClass
  • 25.11Sulphates of Fe and other metalsGroup
  • 25.11.7KrausiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1931Foshag, William F. (1931) Krausite, a new sulfate from California. American Mineralogist, 16 (9) 352-360
  2. 1965Graeber, Edward J., Rosenzweig, Abraham (1965) The unit cell of krausite. American Mineralogist, 50 (3-4) 504-507
  3. 1965Graeber, Edward J., Morosin, Bruno, Rosenzweig, Abraham (1965) The crystal structure of krausite, KFe(SO4)2·H2O. American Mineralogist, 50 (11-12) 1929-1936
  4. 1986Effenberger H, Pertlik F, Zemann J (1986) Refinement of the crystal structure of krausite: a mineral with an interpolyhedral oxygen-oxygen contact shorter than the hydrogen bond American Mineralogist 71 202-205
  5. 2005(2005) Krausite. Handbook of Mineralogy. Mineralogical Society of America
