Leucostaurite

Pb2[B5O9]Cl · 0.5H2O
IMA status
  • Approved
IMA symbol
Lsr
IMA approved
2007
Also known as
  • IMA2007-047
  • Leucostauriet

Where it forms, where it's found

Geological setting

interaction of evaporitic brines within the oxidation zone of a base-metal deposit

Type locality
Asunción Mine
  1. Caracoles
  2. Caracoles mining district
  3. Sierra Gorda
  4. Antofagasta Province
  5. Antofagasta
  6. Chile
1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White to colorless
Streak
White
Tenacity
brittle
Cleavage
Perfect

perfect cleavage parallel to (010), and a good cleavage parallel to (100).

Density
5.071 g/cm³

Optical

Optical type
Biaxial · 2V measured = 30°
Pleochroism
Non-pleochroic
Dispersion
strong, r > v
UV response
a weak, light-yellow fluorescence under short-wavelength UV light and no fluorescence under long-wavelength UV light.
Notes

Mineral reacts with RI fluids. n > 1.790, Gladstone-Dale relationship, for the empirical formula is 1.849

Crystallography

Crystal system
Orthorhombic
Space group
#37
Cell parameters
a = 11.3757(20) Å · b = 11.5051(20) Å · c = 6.5568(7) Å
Ratio a:b:c
1 : 1.011 : 0.576
Z
4
Twinning

Many crystals show interpenetrated twinning [most probably either on (101) or (011)], forming a cruciform assemblage

Type-locality form

Leucostaurite forms thin colorless to white crystals tabular on (010) and striated //[100], sometimes grouped into sheaflike aggregates up to 0.8 mm in length

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
63.08%
8OOxygenOxygen9.515.999151.990
23.14%
5BBoronBoron510.81054.050
8.23%
17ClChlorineChlorine135.45035.450
5.40%
1HHydrogenHydrogen11.0081.008
0.15%
Total656.899100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2007-047
  • Leucostauriet

In other languages

German
IMA 2007-047 · Leukostaurit
Italian
leucostaurite

Classification

Strunz
10th ed.

6.EA.05

  • 6BoratesClass
  • 6.EPentaboratesDivision
  • 6.EANeso-pentaboratesGroup
  • 6.EA.05LeucostauriteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 2010Meisser, N. et al. (2010): The new microporous lead borate, leucostaurite, Pb2[B5O9]Cl · 0.5H2O, from Atacama Desert. 20th General Meeting of the IMA (IMA2010), Budapest, Hungary, August 21-27, CD of Abstracts, p. 485.
  2. 2012Brugger, J., Meisser, N., Ansermet, S., Krivovichev, S. V., Kahlenberg, V., Belton, D., Ryan, C. G. (2012) Leucostaurite, Pb2[B5O9]Cl·0.5H2O, from the Atacama Desert: The first Pb-dominant member of the hilgardite group, and micro-determination of boron in minerals by PIGE. American Mineralogist, 97 (7) 1206-1212 doi:10.2138/am.2012.4082 DOI: 10.2138/am.2012.4082
  3. 2017(2017) Leucostaurite. Handbook of Mineralogy. Mineralogical Society of America
