Hilgardite

Ca2B5O9Cl · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hgr
Discovered
1937
Also known as
  • Calciumhilgardite-2M(Cc)
  • Hilgardiet

Where it forms, where it's found

Geological setting

Salt dome.

Marine evaporite deposits

Type locality
Choctaw Salt Dome
  1. Plaquemine
  2. Iberville Parish
  3. Louisiana
  4. USA

30.3161°, -91.3081°

15recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless · light pink · colourless in transmitted light
Streak
White
Cleavage
Perfect

Perfect on the (010), also on (100) but more difficult to realize.

Fracture
Conchoidal
Density
2.67 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 35° · 2V calc = 52°
Refractive index
1.63 – 1.664
Surface relief
Moderate
Principal indices
nα 1.63 · nβ 1.636 · nγ 1.664
Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 6.297 Å · b = 6.464 Å · c = 6.565 Å
Cell angles
α = 74.24 ° · β = 61.68 ° · γ = 61.26 °
Ratio a:b:c
1 : 1.027 : 1.043
Unit cell volume
198.5 ų
Z
1
Morphology

Crystals tabular (010), with a marked hemimorphic aspect.

Comment

1A polytype

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
48.24%
20CaCalciumCalcium240.07880.156
24.17%
5BBoronBoron510.81054.050
16.29%
17ClChlorineChlorine135.45035.450
10.69%
1HHydrogenHydrogen21.0082.016
0.61%
Total331.662100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Calciumhilgardite-2M(Cc)
  • Hilgardiet

In other languages

French
hilgardite
German
Hilgardit
Spanish
Hilgardita
Italian
Hilgardite
Chinese
氯羟硼钙石 · 水氯硼鈣石

Classification

Strunz
10th ed.

6.ED.05

  • 6BoratesClass
  • 6.EPentaboratesDivision
  • 6.EDTekto-pentaboratesGroup
  • 6.ED.05HilgarditeSpecies
Dana
8th ed.

26.05.14.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.05PentaboratesType
  • 26.05.14HilgarditeGroup
  • 26.05.14.01HilgarditeSpecies
CIM

10.1.8/9/10

  • 10Borates with other anionsClass
  • 10.1Borates with halideGroup
  • 10.1.8/9/10HilgarditeSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1937Hurlbut, Cornelius S., Taylor, and Ralph E. (1937) Hilgardite, a new mineral species, from Choctaw salt dome, Louisiana. American Mineralogist, 22 (10) 1052-1057
  2. 1937Taylor, R.E. (1937) Water-insoluble residue in rock salt of Louisiana salt plugs. Bulletin of the American Association of Petroleum Geologists: 21: 1268-1310.
  3. 1938Hurlbut, Cornelius S. (1938) Parahilgardite, a new triclinic-pedial mineral. American Mineralogist, 23 (11) 765-771
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1959Fleischer, M. (1959) New Mineral Names. American Mineralogist, 44 (9-10). 1102-1104
