Where it forms, where it's found
- Type locality
- Agios Philippos Mine
- Alexandroupoli
- Evros
- Eastern Macedonia and Thrace
- Greece
41.0188°, 25.8193°
Safety & handling
Physical
Optical
- Pleochroism
- Weak
without visible colors, but distinct variation in reflectance values
- Anisotropism
- Strong anisotropism without very pronounced colors
- Tropism
- Anisotropic
- Reflectance R%
- (36.3,38.0,20.0,22.1) 400, (35.0,36.7,20.1,21.1) 440, (34.2,35.8,19.5,20.6) 470, (33.5,35.0,18.9,20.1) 500, (32.5,34.0,18.2,19.5) 546, (32.2,33.7,18.1,19.4) 560, (31.6,33.1,17.8,19.2) 589, (31.0,32.7,17.4,19.0) 520, (30.5,32.1,17.2,18.8) 650, (29.9,31.8,16.9,18.6) 680, (29.6,31.6,16.7,18.5) 700
Crystallography
- Twinning
Twins (only visible in X-ray photographs): mirror on (100) and 60° rotation around [013] for the tetragonal component.
- Type-locality form
occurs in veinlets <1 mm wide of lamellae (maximum length 300 μm) in flow texture
- Comment
Misfit-layer compound of the cylindrite type, with a structure that results from the combination of two heavily modulated triclinic Q and H subcells with a common q wave vector and only one shared reciprocal axis (stacking direction). The Q layer, ~(Pb0.7Sb0.3S), is derived from the NaCl archetype: a = 5.8218(6), b = 5.8645(5), c = 12.1443(13) Å, α = 92.327(7), β = 78.533(9), γ = 90.019(8)°; the H layer, ~(Sn0.85Cu0.3S2), is derived from the CdI2 archetype: a = 3.6661(3), b = 6.3138(5), c = 11.9028(10) Å, α = 92.490(7), β = 90.590(8), γ = 89.986(8) Å.
Chemical composition
Synonyms
- IMA1989-034
- Lévyclaudiet
In other languages
- German
- IMA 1989-034 · Lévyclaudit
- Italian
- Lévyclaudite
Classification
2.HF.25a
- 2Sulfides and SulfosaltsClass
- 2.HSulfosalts of SnS archetypeDivision
- 2.HFWith SnS and PbS archetype structure unitsGroup
- 2.HF.25aLévyclauditeSpecies
03.01.03.01
- 03SulfosaltsClass
- 03.01ø > 4Type
- 03.01.03— unnamed intermediate level —Group
- 03.01.03.01LévyclauditeSpecies
6.1.19
- 6Sulphosalts - Sulphostannates, Sulphogermanates,Sulpharsenates, Sulphantimonates, Sulphovanadates and SulphohalidesClass
- 6.1Sulphostannates and other sulfides containing SnGroup
- 6.1.19LévyclauditeSpecies
Group, growth & confusion
Literature, links & citation
- 1990Moëlo, Yves, Makovicky, Emil, Karup-Møller, Sven, Cervelle, Bernard, Maurel, Colette (1990) La lévyclaudite, Pb8Sn7Cu3(Bi,Sb)3S28, une nouvelle espèce à structure incommensurable, de la série de la cylindrite. European Journal of Mineralogy, 2 (5) 711-724 doi:10.1127/ejm/2/5/0711DOI: 10.1127/ejm/2/5/0711
- 1991Jambor, John L., Burke, Ernst A. J. (1991) New Mineral Names. American Mineralogist, 76 (11-12) 2020-2026
- 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
- 2006Evain, M., Petricek, V., Moëlo, Y., Maurel, C. (2006) First (3+2)-dimensional superspace approach to the structure of levyclaudite-(Sb), a member of the cylindrite-type minerals. Acta Crystallographica: B62: 775-789.
- 2007Piilonen, P. C., Locock, A. J., Rowe, R., Ercit, T. S. (2007) New Mineral Names. American Mineralogist, 92 (4) 703-707 doi:10.2138/am.2007.488DOI: 10.2138/am.2007.488
