Lindackerite

Cu5(AsO4)2(AsO3OH)2 · 9H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ldk
Discovered
1853
Also known as
  • Lindackeriet
  • Lindakerit
  • Lindakerita
  • +1 more

Where it forms, where it's found

Geological setting

Oxidized zones of arsenic-rich copper deposits.

Type locality
Eliáš Mine
  1. Jáchymov
  2. Karlovy Vary District
  3. Karlovy Vary Region
  4. Czech Republic

50.3744°, 12.8828°

13recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Apple-green · light green to colourless in transmitted light
Streak
Pale green to white
Cleavage
Perfect

On (010), perfect.

Fracture
Conchoidal
Density
3.35 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 74° · 2V calc = 72 – 73°
Refractive index
1.626 – 1.728
Surface relief
High
Principal indices
nα 1.626 – 1.632 · nβ 1.662 · nγ 1.725 – 1.728
Pleochroism
Weak

X = Y = Colourless Z = Green

Dispersion
r > v
Extinction
Y ∧ a = 21.3° on {010} and 34.4° on {001}.
Michel-Lévy diagramhighlighted lineδ = 0.0975
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]975 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation975 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 8.035 Å · b = 10.368 Å · c = 6.453 Å
Cell angles
α = 79.6 ° · β = 84.83 ° · γ = 86.7 °
Ratio a:b:c
1 : 1.290 : 0.803
Z
1
Morphology

Crystals lathlike, exhibiting (010), (001), and (101); rosette-like aggregates and crusts.

Comment

Class either _1 or 1; Space Group either P_1 or P1..

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2515.999399.975
38.55%
29CuCopperCopper563.546317.730
30.62%
33AsArsenicArsenic474.922299.688
28.89%
1HHydrogenHydrogen201.00820.160
1.94%
Total1037.553100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Lindackeriet
  • Lindakerit
  • Lindakerita
  • Lindakerite

In other languages

German
Lindackerit
Italian
Lindackerite

Classification

Strunz
10th ed.

8.CE.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.30LindackeriteSpecies
Dana
8th ed.

39.02.06.01

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.02(AB)5[HXO4]2[XO4]2.xH2OType
  • 39.02.06— unnamed intermediate level —Group
  • 39.02.06.01LindackeriteSpecies
CIM

20.1.11

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.1Arsenates of CuGroup
  • 20.1.11LindackeriteSpecies

Group, growth & confusion

In the same group
3 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1853Vogl, J.F., Haidinger, W. (1853) Lindackerit, eine neue Mineralspecies, und Lavendulan von Joachimsthal, nebst Bemerkungen über die Erzführung der Gänge. Jahrbuch der Kaiserlich-Königlichen Geologischen Reichsanstalt: 4: 552-557.
  2. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1956Guillemin, Claude (1956) Contribution à la minéralogie des arséniates, phosphates et vanadates de cuivre. I. — Arséniates de cuivre. Bulletin de Minéralogie, 79 (1) 7-95 doi:10.3406/bulmi.1956.5049DOI: 10.3406/bulmi.1956.5049
  5. 1957Fleischer, M. (1957) New mineral names. American Mineralogist, 42 (1-2). 117-124
