Pradetite

CoCu4(AsO4)2(AsO3OH)2 · 9H2O
IMA status
  • Approved
IMA symbol
Pde
IMA approved
1991
Also known as
  • IMA1991-046
  • Pradetiet

Where it forms, where it's found

Geological setting

Secondary alteration mineral.

Type locality
Cap Garonne Mine
  1. Le Pradet
  2. Toulon
  3. Var
  4. Provence-Alpes-Côte d'Azur
  5. France

43.0814°, 6.0322°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Transparent
Colour
Green
Streak
White
Tenacity
brittle
Cleavage
Perfect
Fracture
Conchoidal
Density
3.33 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 75° · 2V calc = 72°
Refractive index
1.634 – 1.72
Surface relief
High
Principal indices
nα 1.634 · nβ 1.662 · nγ 1.720
Pleochroism
Weak

Z = green, X and Y = colorless.

Dispersion
r < v, strong
Extinction
X ∧ b 20.5° on (001); X ∧ b 35° on (100).
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0860
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]860 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation860 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.434(5) Å · b = 8.059(5) Å · c = 10.399(8) Å
Cell angles
α = 85.70(6) ° · β = 79.14(7) ° · γ = 84.87(2) °
Ratio a:b:c
1 : 1.253 : 1.616
Unit cell volume
526.9 ų
Z
1
Morphology

Fibers, very elongated parallel to [001]. Crystal forms are (001) and (100).

Twinning

Not observed.

Type-locality form

Fibrous aggregates consisting of individual very elongated (parallel to [001]) crystals (0.3 mm x 0.05 mm x 0.15 mm) and massive equidimensional grains (~ 0.2 mm).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2515.999399.975
38.72%
33AsArsenicArsenic474.922299.688
29.01%
29CuCopperCopper463.546254.184
24.61%
27CoCobaltCobalt158.93358.933
5.71%
1HHydrogenHydrogen201.00820.160
1.95%
Total1032.940100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1991-046
  • Pradetiet

In other languages

German
IMA 1991-046 · Pradetit
Italian
pradetite

Classification

Strunz
10th ed.

8.CE.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.30PradetiteSpecies
Dana
8th ed.

39.02.06.05

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.02(AB)5[HXO4]2[XO4]2.xH2OType
  • 39.02.06— unnamed intermediate level —Group
  • 39.02.06.05PradetiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1995Sarp, H., Dominik, B. (1995) Redéfinition de la lindackerite: sa formule chimique, ses données cristallographiques et optiques. [Redefinition of lindackerite: New chemical formula and new crystallographic and optical data]. Archives des Sciences Genève: 48(3): 239-250 (in French with English abstract). https://www.e-periodica.ch/digbib/view?pid=ads-003:1995:48::261#261
  2. 1996Jambor, John L., Grew, Edward S., Roberts, Andrew C. (1996) New mineral names. American Mineralogist, 81. 1513-1518
  3. 2004Jambor, J.L. and Roberts, A.C. (2004) New mineral names. American Mineralogist: 89: 1826-1834.
  4. 2004Hybler, Jiří, Ondruš, Petr, Císařová, Ivana, Petříček, Václav, Veselovský, František (2004) Crystal structure of lindackerite, (Cu,Co,Ni)Cu4(AsO4)2(AsO3OH)2·9H2O from Jachymov, Czech Republic. European Journal of Mineralogy, 15 (6) 1035-1042 doi:10.1127/0935-1221/2003/0015-1035DOI: 10.1127/0935-1221/2003/0015-1035
  5. 2007Burke, E.A.J., Sejkora, J., Sarp, H., Chiappero, P.-J. (2007): Revalidation of pradetite as a mineral. Archives des Sciences- Geneve: 60: 51-54.
