Litharge

PbO
IMA status
  • Approved
  • Grandfathered
IMA symbol
Lit
Discovered
1917
Also known as
  • Goldglätte
  • Litargia
  • Lithargita
  • +1 more

Where it forms, where it's found

Type locality
Unnamed Pb occurrence [10]
  1. Cucamonga Peak
  2. Lytle Creek District
  3. San Bernardino County
  4. California
  5. USA

34.2300°, -117.5542°

153recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Red
Cleavage
Perfect

On (110).

Density
9.14 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
2.535 – 2.665
Surface relief
Very high
Principal indices
nω 2.665 · nε 2.535
Birefringence
0.130
Pleochroism
Non-pleochroic
UV response
Not known to be fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.1300
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1300 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1300 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/nmm
Cell parameters
a = 3.9729 Å · c = 5.0217 Å
Z
2
Morphology

Alteration borders on scales or tablets of massicot; crusts. Artificial crystals are tabular (001).

Comment

See also ICDD 5-561. a = 3.9729, c = 5.0192 Å.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
92.83%
8OOxygenOxygen115.99915.999
7.17%
Total223.199100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Goldglätte
  • Litargia
  • Lithargita
  • Lithargite

In other languages

French
Litharge · Lithargié
German
Bleiglätte · Bleimonoxid · Goldglätte · Lithargit
Spanish
Litargirio
Italian
Giallo di piombo · Giallo ossido di piombo · Litargirio · Spuma argenti
Portuguese
litargírio
Chinese
密陀僧
Russian
Глёт · свинцовый глет
Arabic
مرتك

Classification

Strunz
10th ed.

4.AC.20

  • 4OxidesClass
  • 4.AMetal: Oxygen = 2:1 and 1:1Division
  • 4.ACM:O = 1:1 (and up to 1:1.25); with large cations (+- smaller ones)Group
  • 4.AC.20LithargeSpecies
Dana
8th ed.

04.02.04.01

  • 04Simple OxidesClass
  • 04.02AXType
  • 04.02.04— unnamed intermediate level —Group
  • 04.02.04.01LithargeSpecies
CIM

7.11.21

  • 7Oxides and HydroxidesClass
  • 7.11Oxides of Sn and PbGroup
  • 7.11.21LithargeSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Acta Crystallographica 14: 1304.
  2. 1890Michel (1890), Bull. Soc. Min. 13: 56.
  3. 1910Hintze, Carl (1910): 1(2A): 1934.
  4. 1914Scott, Alexander (1914) Litharge from Zarshuran, Persia. Mineralogical Magazine and Journal of the Mineralogical Society, 17 (80) 143-146 doi:10.1180/minmag.1914.017.80.05 DOI: 10.1180/minmag.1914.017.80.05
  5. 1917Larsen, Esper S. (1917) Massicot and litharge, the two modifications of lead monoxide. American Mineralogist, 2 (2) 18-19
