Where it forms, where it's found
- Geological setting
Manganese deposit
- Type locality
- Tachgagalt Mine
- Tansifte Caïdat
- Agdz Cercle
- Zagora Province
- Drâa-Tafilalet Region
- Morocco
30.7833°, -6.8500°
Physical
Optical
- Optical type
- Biaxial (-) · 2V measured = 20 – 25°
- Pleochroism
- Strong
X = c = safflower-red; Y and Z = opaque (very dark red in very thin sections)
- Optical colour
- Gray to brown
- Anisotropism
- Strong: yellowish green to greenish yellow
- Bireflectance
- Yellowish gray to gray-brown
- Internal reflections
- Dark red, carmine red
- Tropism
- Anisotropic
- Reflectance R%
- (20.2–22.9) 400, (19.3–21.9) 420, (18.4–20.9) 440, (17.7–20.0) 460, (17.0–19.3) 480, (16.5–18.7) 500, (16.2–18.3) 520, (16.0–18.2) 540, (16.0–18.4) 560, (16.0–18.7) 580, (15.9–18.6) 600, (15.7–18.3) 620, (15.5–18.0) 640, (15.4–17.8) 660, (15.2–17.5) 680, (15.1–17.3) 700
Crystallography
- Cell parameters
- a = 9.71(2) Å · b = 10.03(2) Å · c = 3.162(5) Å
- Ratio a:b:c
- 1 : 1.033 : 0.326
- Z
- 4
- Morphology
Prismatic, flattened on (010), with (120), (110), (201), and (011).
- Type-locality form
Prismatic crystals to 5 cm.
- Comment
Point Group: 2/m 2/m 2/m or mm2.; Space Group: Pmab or P21ab.
Chemical composition
Synonyms
- IMA1963-005
- Marokiet
In other languages
- German
- IMA 1963-005 · Marokit
- Italian
- Marokite
Classification
4.BC.05
- 4OxidesClass
- 4.BMetal: Oxygen = 3:4 and similarDivision
- 4.BCWith medium-sized and large cationsGroup
- 4.BC.05MarokiteSpecies
07.02.10.01
- 07Multiple OxidesClass
- 07.02AB2X4Type
- 07.02.10— unnamed intermediate level —Group
- 07.02.10.01MarokiteSpecies
7.4.15
- 7Oxides and HydroxidesClass
- 7.4Oxides of Be, Mg and the alkaline earthsGroup
- 7.4.15MarokiteSpecies
Group, growth & confusion
Literature, links & citation
- 1963Gaudefroy, Christophe, Jouravsky, Georges, Permingeat, François (1963) La marokite, CaMn2O4, une nouvelle espèce minérale. Bulletin de Minéralogie, 86 (4) 359-367 doi:10.3406/bulmi.1963.5665 DOI: 10.3406/bulmi.1963.5665
- 1963Ribaud, P.V., Muan, A. (1963) Melting relations of Ca-O-manganese oxide and MgO-manganese oxide mixtures in air. Journal of the American Ceramic Society: 46: 33-36. (synthetic)
- 1964Fleischer, Michael (1964) New Mineral Names. American Mineralogist, 49 (5-6) 816-821
- 1964Couffon, M.M., Rocher, G., Protas, J. (1964) Determination de la structure de la marokite. Compt. Rend.: 258: 1847-1849. (in French).
- 1966Lepicard, G.; Protas, Jean (1966) Étude structurale de l'oxyde double de manganèse et de calcium orthorhombique CaMn2O4 (marokite). Bulletin de la Société française de Minéralogie et de Cristallographie, 89 (3). 318-324 doi:10.3406/bulmi.1966.5979DOI: 10.3406/bulmi.1966.5979
