Marokite

CaMn3+2O4
IMA status
  • Approved
IMA symbol
Mro
Discovered
1963
Also known as
  • IMA1963-005
  • Marokiet

Where it forms, where it's found

Geological setting

Manganese deposit

Type locality
Tachgagalt Mine
  1. Tansifte Caïdat
  2. Agdz Cercle
  3. Zagora Province
  4. Drâa-Tafilalet Region
  5. Morocco

30.7833°, -6.8500°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black
Streak
Reddish brown
Cleavage
Perfect

(100) Perfect, (001) Good

Density
4.64 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20 – 25°
Pleochroism
Strong

X = c = safflower-red; Y and Z = opaque (very dark red in very thin sections)

Optical colour
Gray to brown
Anisotropism
Strong: yellowish green to greenish yellow
Bireflectance
Yellowish gray to gray-brown
Internal reflections
Dark red, carmine red
Tropism
Anisotropic
Reflectance R%
(20.2–22.9) 400, (19.3–21.9) 420, (18.4–20.9) 440, (17.7–20.0) 460, (17.0–19.3) 480, (16.5–18.7) 500, (16.2–18.3) 520, (16.0–18.2) 540, (16.0–18.4) 560, (16.0–18.7) 580, (15.9–18.6) 600, (15.7–18.3) 620, (15.5–18.0) 640, (15.4–17.8) 660, (15.2–17.5) 680, (15.1–17.3) 700

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 9.71(2) Å · b = 10.03(2) Å · c = 3.162(5) Å
Ratio a:b:c
1 : 1.033 : 0.326
Z
4
Morphology

Prismatic, flattened on (010), with (120), (110), (201), and (011).

Type-locality form

Prismatic crystals to 5 cm.

Comment

Point Group: 2/m 2/m 2/m or mm2.; Space Group: Pmab or P21ab.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese254.938109.876
51.36%
8OOxygenOxygen415.99963.996
29.91%
20CaCalciumCalcium140.07840.078
18.73%
Total213.950100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1963-005
  • Marokiet

In other languages

German
IMA 1963-005 · Marokit
Italian
Marokite

Classification

Strunz
10th ed.

4.BC.05

  • 4OxidesClass
  • 4.BMetal: Oxygen = 3:4 and similarDivision
  • 4.BCWith medium-sized and large cationsGroup
  • 4.BC.05MarokiteSpecies
Dana
8th ed.

07.02.10.01

  • 07Multiple OxidesClass
  • 07.02AB2X4Type
  • 07.02.10— unnamed intermediate level —Group
  • 07.02.10.01MarokiteSpecies
CIM

7.4.15

  • 7Oxides and HydroxidesClass
  • 7.4Oxides of Be, Mg and the alkaline earthsGroup
  • 7.4.15MarokiteSpecies

Group, growth & confusion

In the same group
6 members

Literature, links & citation

Citations
  1. 1963Gaudefroy, Christophe, Jouravsky, Georges, Permingeat, François (1963) La marokite, CaMn2O4, une nouvelle espèce minérale. Bulletin de Minéralogie, 86 (4) 359-367 doi:10.3406/bulmi.1963.5665 DOI: 10.3406/bulmi.1963.5665
  2. 1963Ribaud, P.V., Muan, A. (1963) Melting relations of Ca-O-manganese oxide and MgO-manganese oxide mixtures in air. Journal of the American Ceramic Society: 46: 33-36. (synthetic)
  3. 1964Fleischer, Michael (1964) New Mineral Names. American Mineralogist, 49 (5-6) 816-821
  4. 1964Couffon, M.M., Rocher, G., Protas, J. (1964) Determination de la structure de la marokite. Compt. Rend.: 258: 1847-1849. (in French).
  5. 1966Lepicard, G.; Protas, Jean (1966) Étude structurale de l'oxyde double de manganèse et de calcium orthorhombique CaMn2O4 (marokite). Bulletin de la Société française de Minéralogie et de Cristallographie, 89 (3). 318-324 doi:10.3406/bulmi.1966.5979DOI: 10.3406/bulmi.1966.5979
