Martyite

Zn3V2O7(OH)2 · 2H2O
IMA status
  • Approved
IMA symbol
Myi
IMA approved
2007
Also known as
  • IMA2007-026
  • Martyiet

Where it forms, where it's found

Type locality
Blue Cap Mine
  1. La Sal Creek Mining District
  2. San Juan County
  3. Utah
  4. USA

38.3368°, -109.0609°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale orange yellow
Tenacity
flexible
Cleavage
Perfect

perfect on (001) and good on (110)

thin flakes slightly flexible, coarser plates brittle with a curved fracture

Density
3.37 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.793 – 1.806
Surface relief
High
Principal indices
nω 1.793 · nε 1.806
Pleochroism
Strong

O (red-orange) >> E (yellow)

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#84
Cell parameters
a = 6.0818 Å · c = 7.1793 Å
Unit cell volume
229.97 ų
Z
1
Morphology

thin plates and flakes with (001) prominent. A poorly developed (110) also observed.

Type-locality form

a V-U oxide-replacement assemblage developed at the expense of organic material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc365.380196.140
40.86%
8OOxygenOxygen1115.999175.989
36.66%
23VVanadiumVanadium250.942101.884
21.22%
1HHydrogenHydrogen61.0086.048
1.26%
Total480.061100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2007-026
  • Martyiet

In other languages

German
IMA 2007-026 · Martyit
Italian
martyite

Classification

Strunz
10th ed.

8.FD.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.FPolyphosphates, Polyarsenates, [4]-PolyvanadatesDivision
  • 8.FDPolyphosphates, etc., with OH and H2OGroup
  • 8.FD.05MartyiteSpecies
Dana
8th ed.

40.03.10.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.10— unnamed intermediate level —Group
  • 40.03.10.02MartyiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2008Green, D. I., Hubbard, N., Ince, F. (2008) A review of the occurrences of the copper vanadate materials volborthite and tangeite in the British Isles. Journal of the Russell Society, 11. 54-58
  2. 2008Kampf, A. R., Steele, I. M. (2008) Martyite, a new mineral species related to volborthite: Description and crystal structure. The Canadian Mineralogist, 46 (3) 687-692 doi:10.3749/canmin.46.3.687 DOI: 10.3749/canmin.46.3.687
  3. 2011(2011) Martyite. Handbook of Mineralogy. Mineralogical Society of America
