Matthiasweilite

PbTe4+O3
IMA status
  • Approved
IMA symbol
Mtw
Also known as
  • Matthiasweiliet

Where it forms, where it's found

Geological setting

Secondary mineral.

Type locality
Mine dump
  1. Delamar Mine
  2. Delamar Mining District
  3. Lincoln County
  4. Nevada
  5. USA

37.4625°, -114.7689°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Light yellow
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
7.282 g/cm³

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.0256(4) Å · b = 10.6345(6) Å · c = 11.9965(8) Å
Cell angles
α = 78.513(6) ° · β = 83.104(6) ° · γ = 84.083(6) °
Ratio a:b:c
1 : 1.514 : 1.708
Z
10
Type-locality form

Tightly intergrown masses of light yellow crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
54.13%
52TeTelluriumTellurium1127.600127.600
33.33%
8OOxygenOxygen315.99947.997
12.54%
Total382.797100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Matthiasweiliet

In other languages

German
IMA 2021-069 · Matthiasweilit

Classification

Strunz
10th ed.

4.JK

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JKMatthiasweiliteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2022(2022) Matthiasweilite. Handbook of Mineralogy. Mineralogical Society of America
  2. 2022Kampf, Anthony R., Missen, Owen P., Mills, Stuart J., Ma, Chi, Housley, Robert M., Chorazewicz, Marek, Marty, Joe, Coolbaugh, Mark, Momma, Koichi (2022) Matthiasweilite, PbTe4+O3, a New Tellurite Mineral from the Delamar Mine, Lincoln County, Nevada, USA. The Canadian Mineralogist, 60 (5) 805-814 doi:10.3749/canmin.2200015DOI: 10.3749/canmin.2200015
