Plumbotellurite

Pb(Te4+O3)
IMA status
  • Approved
IMA symbol
Pbtlr
Discovered
1982
Also known as
  • IMA1980-102
  • Plumbotelluriet
  • Plumbotellurita

Where it forms, where it's found

Geological setting

Oxidation zone of a Te-rich deposit.

Type locality
Zhana-Tyube deposit
  1. Stepnyak group
  2. Stepnogorsk
  3. Akmola Region
  4. Kazakhstan

52.5414°, 71.7279°

10recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Translucent
Colour
Gray · brown to yellow-brown
Streak
Yellow-gray
Cleavage
None Observed
Density
7.2 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 50° · 2V calc = 64°
Refractive index
2.19 – 2.35
Surface relief
Very high
Principal indices
nα 2.19 · nβ 2.23 · nγ 2.35
Dispersion
relatively strong
Optical colour
Gray to brownish gray
Anisotropism
Distinct
Tropism
Anisotropic
Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 26.442(5) Å · b = 4.6010(9) Å · c = 17.890(4) Å
Cell angles
β = 107.01(3) °
Ratio a:b:c
1 : 0.174 : 0.677
Type-locality form

Replacement rims and pseudomorphs of altaite.

Comment

Originally described as orthorhombic. Determined to be monoclinic by Back (1990).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
54.13%
52TeTelluriumTellurium1127.600127.600
33.33%
8OOxygenOxygen315.99947.997
12.54%
Total382.797100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1980-102
  • Plumbotelluriet
  • Plumbotellurita

In other languages

French
Plumbotellurite
German
IMA 1980-102 · Plumbotellurit
Italian
Plumbotellurite

Classification

Strunz
10th ed.

4.JK.55

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.55PlumbotelluriteSpecies
Dana
8th ed.

34.01.04.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.01A(XO3)Type
  • 34.01.04— unnamed intermediate level —Group
  • 34.01.04.01PlumbotelluriteSpecies
CIM

28.3.14

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.14PlumbotelluriteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Anzeiger Österreichen Akademie der Wissenschaften, Mathematisch-Naturwissenschaftliche Klasse: K1 Nd. 06: 129.
  2. 1982Fleischer, M., Cabri, L.J., Chao, G.Y., Mandarino, J.A., Pabst, A. (1982) New mineral names. American Mineralogist: 67: 1074-1082.
  3. 1982Spiridonov, E.M., Tananeyva, O.I. (1982) Plumbotellurite, α-PbTeO3, a new mineral. Doklady Akademii Nauk SSSR, 262, 1231-1235.
  4. 1990Back M.E. (1990) A Study of Tellurite Minerals: Their Physical and Chemical Data Compatibility, and Structural Crystallography. MSc Thesis, University of Toronto, Canada.
  5. 2018Weil, W., Shirkhanlou, M., Füglein, E., Libowitzky, E. (2018): Determination of the correct composition of “hydrous lead(II) oxotellurate(IV)” as PbTeO3, crystallizing as a new polymorph. Crystals: 8: 51.
