Mcbirneyite

Cu3(VO4)2
IMA status
  • Approved
IMA symbol
Mbn
Discovered
1987
Also known as
  • IMA1985-007
  • Mcbirneyiet

Where it forms, where it's found

Geological setting

Fumerole on basaltic volcano.

fumeroles

Type locality
Izalco Volcano
  1. Sonsonate Department
  2. El Salvador

13.8137°, -89.6326°

3recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Opaque
Colour
Black
Density
4.50 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
Medium dark gray.
Tropism
Anisotropic
Reflectance R%
(18.5) 470, (17.5) 546, (18.7) 589, (20.6) 650
UV response
Not fluorescent.
Reflected-light panel
18.8 %isotropic · single curve
Specimen sRGB 164, 108, 59
White reference100 % reflector under same lamp
Reflected colour
Medium dark gray.

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.34 Å · b = 6.51 Å · c = 5.17 Å
Cell angles
α = 88.61 ° · β = 68.11 ° · γ = 69.22 °
Ratio a:b:c
1 : 1.219 : 0.968
Z
1
Type-locality form

Anhedral crystals up to 200 μm in greatest dimension.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
29CuCopperCopper363.546190.638
45.33%
8OOxygenOxygen815.999127.992
30.44%
23VVanadiumVanadium250.942101.884
24.23%
Total420.514100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1985-007
  • Mcbirneyiet

In other languages

German
IMA 1985-007 · Mcbirneyit
Italian
Mcbirneyite

Classification

Strunz
10th ed.

8.AB.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ABWith medium-sized cationsGroup
  • 8.AB.35McbirneyiteSpecies
Dana
8th ed.

38.03.10.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.03(AB)3(XO4)2Type
  • 38.03.10— unnamed intermediate level —Group
  • 38.03.10.01McbirneyiteSpecies
CIM

21.1.10

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.1Vanadates of the alkalis and CuGroup
  • 21.1.10McbirneyiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1982Coing-Boyat, J. (1982) Structure de la variété ordinaire, triclinique, de l'orthovanadate de cuivre(II), Cu3(VO4)2. Acta Crystallographica: B38: 1546-1548.
  2. 1987Hughes, John M., Christian, Barbara S., Finger, Larry W., Malinconico, Lawrence L. (1987) Mcbirneyite, Cu3(VO4)2, a new sublimate mineral from the fumaroles of Izalco volcano, El Salvador. Journal of Volcanology and Geothermal Research, 33 (1) 183-190 doi:10.1016/0377-0273(87)90060-6DOI: 10.1016/0377-0273(87)90060-6
  3. 1988Jambor, John L., Ercit, Ernst A. J. Burke T. Scott, Grice, Joel D. (1988) New Mineral Names. American Mineralogist, 73 (11-12) 1492-1499
  4. 2005(2005) Mcbirneyite. Handbook of Mineralogy. Mineralogical Society of America
