Meliphanite

Ca4(Na,Ca)4Be4AlSi7O24(F,O)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mph
Discovered
1852
Also known as
  • Melinophan
  • Melinophane
  • Meliphan
  • +2 more

Where it forms, where it's found

Type locality
Langesundsfjorden
  1. Norway
38recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
yellow · yellowish red · nearly colourless
Streak
white
Cleavage
Perfect
Fracture
Conchoidal

Optical

Optical type
Uniaxial (-)
Refractive index
1.592 – 1.672
Surface relief
Moderate
Principal indices
nω 1.611 – 1.664 · nε 1.592 – 1.672
Michel-Lévy diagramhighlighted lineδ = 0.0055
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]55 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation55 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#127
Cell parameters
a = 10.51 Å · c = 9.88 Å
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
37.45%
20CaCalciumCalcium840.078320.624
26.80%
14SiSiliconSilicon728.085196.595
16.44%
11NaSodiumSodium422.99091.960
7.69%
9FFluorineFluorine418.99875.992
6.35%
4BeBerylliumBeryllium49.01236.048
3.01%
13AlAluminiumAluminium126.98226.982
2.26%
Total1196.173100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • K
  • H2O

Synonyms

  • Melinophan
  • Melinophane
  • Meliphan
  • Meliphaniet
  • Meliphanita

In other languages

German
Meliphanit
Italian
Melifanite
Japanese
メリフェン石

Classification

Strunz
10th ed.

9.DP.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DPTransitional ino-phyllosilicate structuresGroup
  • 9.DP.05MeliphaniteSpecies
Dana
8th ed.

55.04.02.05

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.04Si2O7 Groups, Generally with No Additional Anions with cations in [8] and lower coordinationType
  • 55.04.02Fresnoite groupGroup
  • 55.04.02.05MeliphaniteSpecies
CIM

17.2.5

  • 17Silicates Containing other AnionsClass
  • 17.2Silicates with fluorideGroup
  • 17.2.5MeliphaniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1852Scheerer, Th. (1852) Melinophan, eine neue Mineralspecies [Melinophane, a new mineral species]. Journal für Praktische Chemie, 55 (1) 449-451 doi:10.1002/prac.18520550188DOI: 10.1002/prac.18520550188
  2. 1856Rammelsberg, C. (1856) Ueber die Identität des Leucophans und Melinophans. Annalen der Physik und Chemie, 174. 257-261 doi:10.1002/andp.18561740608DOI: 10.1002/andp.18561740608
  3. 1930Zachariasen, W. H. (1930) On Meliphanite and Leucophanite. Zeitschrift für Kristallographie, 74 (1-6). 226-229 doi:10.1524/zkri.1930.74.1.226DOI: 10.1524/zkri.1930.74.1.226
  4. 1967Dal Negro, A., Rossi, G., Ungaretti, L. (1967) The crystal structure of meliphanite. Acta Crystallographica, 23 (2) 260-264 doi:10.1107/s0365110x67002579DOI: 10.1107/s0365110x67002579
  5. 2001(2001) Meliphanite. Handbook of Mineralogy. Mineralogical Society of America
