Homilite

Ca2Fe2+B2Si2O10
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hom
Discovered
1860

Where it forms, where it's found

Geological setting

Nepheline syenite pegmatite

syenite pegmatite

Type locality
Stokkøya
  1. Larvik Commune
  2. Vestfold
  3. Norway
7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Greenish black to brownish black

Translucent in very thin splinters

Streak
Grey
Tenacity
brittle
Cleavage
None Observed
Fracture
Sub-Conchoidal
Density
3.34 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80° · 2V calc = 84°
Refractive index
1.715 – 1.738
Surface relief
High
Principal indices
nα 1.715 · nβ 1.725 · nγ 1.738
Dispersion
none
Extinction
Z = b; Y ∧ c = -1°.
Notes

Absorption: Y > X > Z.

Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 9.78 Å · b = 7.61 Å · c = 4.78 Å
Cell angles
β = 90.56 °
Ratio a:b:c
1 : 0.778 : 0.489
Morphology

Observed forms (after Brögger 1890): (001), (011), (021), (010), (100), (720), (310), (210), (110), (890), (120), (201), (111), (211), (111), (421), (221), {10·5·2}.

Twinning

Frequently occurs as twins: with (100) as the twin plane, with (001) as the twin plane, with (430) as the twin pane or with (120) as the twin plane.

Type-locality form

Black to black-brownish crystal

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
42.80%
20CaCalciumCalcium240.07880.156
21.45%
14SiSiliconSilicon228.08556.170
15.03%
26FeIronIron155.84555.845
14.94%
5BBoronBoron210.81021.620
5.78%
Total373.781100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mn
  • Na

In other languages

French
Homilite
German
Homilit
Spanish
Homilita
Italian
Homilite
Japanese
ホミライト

Classification

Strunz
10th ed.

9.AJ.20

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.20HomiliteSpecies
Dana
8th ed.

54.02.1b.05

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.02Borosilicates and Some Beryllosilicates with B in [4] coordinationType
  • 54.02.1b— unnamed intermediate level —Group
  • 54.02.1b.05HomiliteSpecies
CIM

17.5.48

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.48HomiliteSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1876Paijkull, S. R. (1876) Homilit, ett mineral från Brevig i Norge. Geologiska Föreningen i Stockholm Förhandlingar, 3 (7) 229-232 doi:10.1080/11035897609446186DOI: 10.1080/11035897609446186
  2. 1877Des Cloizeaux, Alfred Louis Oliver, Damour, A. (1877) Note sur la forme cristalline, les propriétés optiques et la composition chimique de la homilite [Note on the crystal form, optical properties and chemical composition of homilite]. Annales de chimie et de physique, Paris, S. 5 Vol. 12. 405-412
  3. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  4. 1985Miyawaki, R., Nakai, I., Nagashima, K. (1985) Structure of homilite, Ca2.00(Fe0.90Mn0.03)B2.00Si2.00O9.86(OH)0.14. Acta Crystallographica Section C Crystal Structure Communications, 41 (1) 13-15 doi:10.1107/s010827018500261xDOI: 10.1107/s010827018500261x
  5. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
