Meniaylovite

Ca4AlSi(SO4)F13 · 12H2O
IMA status
  • Approved
IMA symbol
Myl
IMA approved
2002
Also known as
  • IMA2002-050
  • Meniayloviet
  • Menyailovite

Where it forms, where it's found

Geological setting

Alteration of volcanic rocks under fumarole gases.

Type locality
First scoria cone
  1. Northern Breakthrough (North Breach)
  2. Great Fissure eruption (Main Fracture)
  3. Tolbachik Volcanic field
  4. Milkovsky District
  5. Kamchatka Krai
  6. Russia

55.6815°, 160.2373°

9recorded occurrences
Source · OpenStreetMap

Physical

Transparency
Transparent
Colour
White to yellowish

Optical

Optical type
Isotropic
Surface relief
Low
Principal indices
n 1.43
Tropism
Isotropic
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.430

Crystallography

Crystal system
Isometric
Space group
#200
Cell parameters
a = 16.722 Å
Morphology

Octahedral or cube-octahedral crystals.

Type-locality form

Colourless or white octahedral and cube-octahedral crystals up to 0.2 mm and yellowish-white crusts.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
33.05%
9FFluorineFluorine1318.998246.974
31.88%
20CaCalciumCalcium440.078160.312
20.70%
16SSulfurSulfur132.06032.060
4.14%
14SiSiliconSilicon128.08528.085
3.63%
13AlAluminiumAluminium126.98226.982
3.48%
1HHydrogenHydrogen241.00824.192
3.12%
Total774.589100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2002-050
  • Meniayloviet
  • Menyailovite

In other languages

German
IMA 2002-050 · Meniaylovit · Menyailovit
Italian
meniaylovite

Classification

Strunz
10th ed.

3.CG.10

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CGAluminofluorides with CO3, SO4, PO4Group
  • 3.CG.10MeniayloviteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1981Mathew, M., Takagi, S., Waerstad, K. R., Frazier, A. W. (1981) The crystal structure of synthetic chukhrovite, Ca4AlSi(SO4)F13 · 12H2O. American Mineralogist, 66 (3-4) 392-397
  2. 2003Grice, J. D.; Ferraris, G. (2003) New minerals approved in 2002 and nomenclature modifications approved in 1998-2002 by the Commission on the New Minerals and Mineral Names, International Mineralogical Association. The Canadian Mineralogist, 41 (3). 795-802 doi:10.2113/gscanmin.41.3.795 DOI: 10.2113/gscanmin.41.3.795
  3. 2004Vergasova, L.P., Semyonova, T.F., Epifanova, V.B., Filatov, S.K., Chubarov, V.M. (2004) Meniaylovite, Ca4AlSi(SO4)F13·12H2O, a new mineral of volcanic exhalations. Vulkanologiya i Seismologiya: 2: 3-5.
  4. 2007(2007) New Minerals From Former Soviet Union Countries 1998-2006. Mineralogical Almanac Vol. 11
  5. 2021(2021) Meniaylovite. Handbook of Mineralogy. Mineralogical Society of America
