Meyrowitzite

Ca(UO2)(CO3)2 · 5H2O
IMA status
  • Approved
IMA symbol
Mey
IMA approved
2018
Also known as
  • IMA2018-039
  • Meyrowitziet

Where it forms, where it's found

Type locality
Markey Mine
  1. Red Canyon Mining District
  2. San Juan County
  3. Utah
  4. USA

37.5493°, -110.3021°

1recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow
Streak
Very pale yellow
Tenacity
brittle
Cleavage
Perfect

(101)

Fracture
Irregular/Uneven
Density
2.70 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 53.0°
Refractive index
1.52 – 1.561
Surface relief
Moderate
Principal indices
nα 1.520 · nβ 1.528 · nγ 1.561
Pleochroism
Visible

pale yellow, X ≈ Y < Z

Dispersion
weak, r>v
UV response
Using 405 nm laser, weak greenish yellow to moderate greenish blue
Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 12.376(3) Å · b = 16.087(1) Å · c = 20.134(2) Å
Cell angles
β = 107.68(1) °
Ratio a:b:c
1 : 1.300 : 1.627
Unit cell volume
3819.3 ų
Z
12
Morphology

Elongate on [010], flattened on (100), and exhibiting the forms (100), (001), (101), (110), and (011).

Type-locality form

Blades to 0.2 mm on on calcite-veined asphaltum

Comment

Spacegroup: P21/n

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
45.76%
8OOxygenOxygen1315.999207.987
39.98%
20CaCalciumCalcium140.07840.078
7.70%
6CCarbonCarbon212.01124.022
4.62%
1HHydrogenHydrogen101.00810.080
1.94%
Total520.196100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2018-039
  • Meyrowitziet

In other languages

German
IMA 2018-039 · Meyrowitzit

Classification

Strunz
10th ed.

5.EC.20

  • 5CarbonatesClass
  • 5.EUranyl CarbonatesDivision
  • 5.ECUO2:CO3 < 1:1 - 1:2Group
  • 5.EC.20MeyrowitziteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2018Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2018) CNMNC Newsletter No. 44, New minerals and nomenclature modifications approved in 2018. Mineralogical Magazine, 82 (4) 1015-1021 doi:10.1180/mgm.2018.148DOI: 10.1180/mgm.2018.148
  2. 2019Kampf, Anthony R., Plášil, Jakub, Olds, Travis A., Nash, Barbara P., Marty, Joe, Belkin, Harvey E. (2019) Meyrowitzite, Ca(UO2)(CO3)2·5H2O, a new mineral with a novel uranyl-carbonate sheet. American Mineralogist, 104 (4) 603-610 doi:10.2138/am-2019-6814 DOI: 10.2138/am-2019-6814
  3. 2020(2020) Meyrowitzite. Handbook of Mineralogy. Mineralogical Society of America
