Zellerite

Ca(UO2)(CO3)2 · 5H2O
IMA status
  • Approved
IMA symbol
Zel
Discovered
1963
IMA approved
1965
Also known as
  • IMA1965-031
  • Zelleriet

Where it forms, where it's found

Type locality
Lucky MC mine (Lucky Mac)
  1. Fremont County
  2. Wyoming
  3. USA

42.8169°, -107.6129°

15recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light lemon-yellow
Cleavage
Imperfect/Fair

one parallel to elongation

Density
3.25 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 25 – 30° · 2V calc = 48°
Refractive index
1.536 – 1.697
Surface relief
Moderate
Principal indices
nα 1.536 · nβ 1.559 · nγ 1.697
Pleochroism
Weak

X=Y= colorless; Z = pale yellow

Dispersion
r > v
UV response
Fluoresces patchy green under SW and LW UV
Michel-Lévy diagramhighlighted lineδ = 0.1610
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1610 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1610 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 11.220(15) Å · b = 19.252(16) Å · c = 4.933(16) Å
Ratio a:b:c
1 : 1.716 : 0.440
Z
4
Comment

Point Group: 2/m 2/m 2/m or mm2.; Space Group: Pmmm or Pmn21.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
45.76%
8OOxygenOxygen1315.999207.987
39.98%
20CaCalciumCalcium140.07840.078
7.70%
6CCarbonCarbon212.01124.022
4.62%
1HHydrogenHydrogen101.00810.080
1.94%
Total520.196100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1965-031
  • Zelleriet

In other languages

German
IMA 1965-031 · Zellerit
Spanish
Zellerita
Italian
Zellerite
Chinese
碳钙铀矿

Classification

Strunz
10th ed.

5.EC.10

  • 5CarbonatesClass
  • 5.EUranyl CarbonatesDivision
  • 5.ECUO2:CO3 < 1:1 - 1:2Group
  • 5.EC.10ZelleriteSpecies
Dana
8th ed.

15.03.01.01

  • 15Hydrated Normal CarbonatesClass
  • 15.03AmBn(XO3)p·xH2O, with (m+n):p = 1:1Type
  • 15.03.01— unnamed intermediate level —Group
  • 15.03.01.01ZelleriteSpecies
CIM

11.11.7

  • 11CarbonatesClass
  • 11.11Carbonates of Cr and UGroup
  • 11.11.7ZelleriteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1963New Mexico Bureau of Mines and Mineral Resources, Memoir (1963): 15: 21.
  2. 1964Fleischer, Michael (1964) New Mineral Names. American Mineralogist, 49 (3-4) 439-448
  3. 1966Coleman, R. G., Ross, D. R., Meyrowitz, R. (1966) Zellerite and metazellerite, new uranyl carbonates. American Mineralogist, 51 (11-12) 1567-1578
  4. 2005(2005) Zellerite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Frost, Ray L., Dickfos, Marilla J., Čejka, Jiří (2008) Raman spectroscopic study of the uranyl carbonate mineral zellerite. Journal of Raman Spectroscopy, 39 (5). 582-586 doi:10.1002/jrs.1879DOI: 10.1002/jrs.1879
