Molybdofornacite

CuPb2(MoO4)(AsO4)(OH)
IMA status
  • Approved
IMA symbol
Mfor
IMA approved
1982
Also known as
  • IMA1982-062
  • Molybdofornaciet

Where it forms, where it's found

Geological setting

Oxidation zone

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

18recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Transparent · Translucent
Colour
Light green · olive green
Streak
Pale Yellow
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
6.57 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.05 – 2.15
Surface relief
Very high
Principal indices
nα 2.05 · nγ 2.15
Birefringence
0.10
Pleochroism
Strong

X and Y pale yellow, Z green yellow.

Dispersion
r < v strong
UV response
Not known to fluoresce in UV
Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 8.100(5) Å · b = 5.946(3) Å · c = 17.651(1) Å
Cell angles
β = 109.17(5) °
Ratio a:b:c
1 : 0.734 : 2.179
Z
4
Twinning

Rare “butterfly” contact twins, at 120 degrees.

Type-locality form

Minute lath-like crystals on dioptase

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
52.20%
8OOxygenOxygen915.999143.991
18.14%
42MoMolybdenumMolybdenum195.95095.950
12.09%
33AsArsenicArsenic174.92274.922
9.44%
29CuCopperCopper163.54663.546
8.00%
1HHydrogenHydrogen11.0081.008
0.13%
Total793.817100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-062
  • Molybdofornaciet

In other languages

German
IMA 1982-062 · Molybdofornacit
Italian
Molibdofornacite · Molybdofornacite

Classification

Strunz
10th ed.

7.FC.10

  • 7SulfatesClass
  • 7.FChromatesDivision
  • 7.FCWith PO4, AsO4, SiO4Group
  • 7.FC.10MolybdofornaciteSpecies
Dana
8th ed.

43.04.03.03

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.03Vauquelinite GroupGroup
  • 43.04.03.03MolybdofornaciteSpecies
CIM

22.5.5

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.5Phosphates, arsenates or vanadates with chromate, molybdate, niobate or tantalateGroup
  • 22.5.5MolybdofornaciteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1983Medenbach, O., Abraham, K., Gebert, W. (1983) Molybdofornacit, ein neues Blei-Kupfer-Arsenat-Molybdat-Hydroxid von Tsumeb, Namibia. Neues Jahrbuch für Mineralogie - Monatshefte, 1983. 289-295
  2. 1984Dunn, Pete J., Chao, George Y., Grice, Joel D., Ferraiolo, James A., Fleischer, Michael, Pabst, Adolf, Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (5-6) 565-569
  3. 1994Jambor, John L., Grew, Edward S., Roberts, Andrew C. (1994) New Mineral Names. American Mineralogist, 79 (11-12) 1210-1230
  4. 1994Nickel, Ernest H., Hitchen, Greg J. (1994) The Phosphate Analog of Molybdofornacite from Whim Creek, Western Australia. The Mineralogical Record, 25 (3) 203-204
  5. 2005(2005) Molybdofornacite. Handbook of Mineralogy. Mineralogical Society of America
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Molybdofornacite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/molybdofornacite-2734},
  note      = {Accessed 2026-05-11}
}
