Monazite-(Nd)

Nd(PO4)
IMA status
  • Approved
IMA symbol
Mnz-Nd
IMA approved
1986
Also known as
  • IMA1986-052
  • Monaziet-(Nd)

Where it forms, where it's found

Geological setting

In small fissures in gneiss blocks, or druses of aplitic to pegmatitic veins in a schistose gneiss with abundant white mica.

Type locality
Monte Giove
  1. Vallone del Vannino
  2. Formazza
  3. Verbano-Cusio-Ossola Province
  4. Piedmont
  5. Italy

46.3662°, 8.3890°

35recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright rose-red
Cleavage

By analogy to monazite-(Ce), probably (100) distinct and (010) poor.

Density
5.43 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.77 – 1.85
Surface relief
Very high
Principal indices
nα 1.77 – 1.80 · nβ 1.7705 – 1.802 · nγ 1.83 – 1.85
Dispersion
extreme
Michel-Lévy diagramhighlighted lineδ = 0.0550
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]550 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation550 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.745(4) Å · b = 6.964(4) Å · c = 6.435(4) Å
Cell angles
β = 103.65(4) °
Ratio a:b:c
1 : 1.032 : 0.954
Z
4
Type-locality form

Long prismatic crystals, bright rose in colour.

Comment

P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
60NdNeodymiumNeodymium1144.242144.242
60.30%
8OOxygenOxygen415.99963.996
26.75%
15PPhosphorusPhosphorus130.97430.974
12.95%
Total239.212100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1986-052
  • Monaziet-(Nd)

In other languages

German
IMA 1986-052 · Monazit-(Nd)
Italian
Monazite- · Monazite-(Nd)

Classification

Strunz
10th ed.

8.AD.50

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.50Monazite-(Nd)Species
Dana
8th ed.

38.04.03.05

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.04AXO4Type
  • 38.04.03Monazite Group (Monoclinic: P21/n)Group
  • 38.04.03.05Monazite-(Nd)Species
CIM

19.9.5

  • 19PhosphatesClass
  • 19.9Phosphates of rare earths and ScGroup
  • 19.9.5Monazite-(Nd)Species

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1980Masksimovic, Z., Panto, Gy. (1980) Bastnasite-(La) and monazite-eNd), a new variety of monazite, from the Marmara bauxite deposit (Greece). Bull. Acad. Serbe Sci. Art, 72(20), 35-42.
  2. 1983Dunn, P. J.; Cabri, L. J.; Clark, A. M.; Fleischer, M. (1983) New mineral names. American Mineralogist, 68 (7-8). 849-852
  3. 1987Graeser, St. & Schwander, H. (1987): Gasparite-(Ce) and monazite-(Nd): two new minerals to the monazite group from the Alps. Schweizerische mineralogische und petrographische Mitteilungen, 67, 101-113.
  4. 1988Jambor, John L., Ercit, Ernst A. J. Burke T. Scott, Grice, Joel D. (1988) New Mineral Names. American Mineralogist, 73 (11-12) 1492-1499
  5. 2005(2005) Monazite-(Nd). Handbook of Mineralogy. Mineralogical Society of America
