Montroydite

HgO
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mtyd
Discovered
1903

Where it forms, where it's found

Type locality
Terlingua Mining District
  1. Texas
  2. USA
31recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Deep red · brownish red to brown · Orange-red to pale yellow in transmitted light · with decreasing thickness
Streak
Yellow-brown
Tenacity
sectile
Cleavage
Perfect

Perfect (010).

Density
11.23 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.37 – 2.65
Surface relief
Very high
Principal indices
nα 2.37 · nβ 2.5 · nγ 2.65
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.2800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2800 nm6th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2800 nm
Order6th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#69
Cell parameters
a = 5.52 Å · b = 6.6 Å · c = 3.52 Å
Ratio a:b:c
1 : 1.196 : 0.638
Morphology

Long prismatic [001]; also equant or rarely flattened (111). Terminal faces often striated; on (011) parallel [100], on (201) parallel [101], the pyramids often with several sets of striae. As worm-like, tubular, or spherical aggregates consisting usually of minute prismatic crystals. Massive, powdery, or banded. Crystals often bent or twisted.

Twinning

Crystals glide readily: bent-gliding and twist-gliding with T(010) and t[001]; also other, unidentified gliding elements.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury1200.592200.592
92.61%
8OOxygenOxygen115.99915.999
7.39%
Total216.591100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
HgO · montroydite
German
Montroydit
Spanish
montroydita
Italian
montroydite
Chinese
橙汞矿

Classification

Strunz
10th ed.

4.AC.15

  • 4OxidesClass
  • 4.AMetal: Oxygen = 2:1 and 1:1Division
  • 4.ACM:O = 1:1 (and up to 1:1.25); with large cations (+- smaller ones)Group
  • 4.AC.15MontroyditeSpecies
Dana
8th ed.

04.02.06.01

  • 04Simple OxidesClass
  • 04.02AXType
  • 04.02.06— unnamed intermediate level —Group
  • 04.02.06.01MontroyditeSpecies
CIM

7.5.12

  • 7Oxides and HydroxidesClass
  • 7.5Oxides of Zn, Cd and HgGroup
  • 7.5.12MontroyditeSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1903Moses, A.J. (1903) Eglestonite, terlinguaite, and montroydite, new mercury minerals from Terlingua, Texas. American Journal of Science: 16: 253-263.
  2. 1904Moses, A. J. (1904) Eglestonit, Terlinguaït und Montroydit, neue Quecksilbermineralien von Terlingua in Texas. Zeitschrift für Kristallographie, 39 (1). 3-13 doi:10.1524/zkri.1904.39.1.3DOI: 10.1524/zkri.1904.39.1.3
  3. 1909Hillebrand, W.F.; Schaller, W.T. (1909) The mercury minerals from Terlingua, Texas. Bulletin 405. US Geological Survey p.1-174. doi:10.3133/b405 DOI: 10.3133/b405
  4. 1932Bird, Paul H. (1932) A new occurrence and x-ray study of mosesite. American Mineralogist, 17 (12) 541-550
  5. 1934Woodhouse, C. D. (1934) A new occurrence of montroydite in California. American Mineralogist, 19 (12) 603-604
