Mopungite

NaSb5+(OH)6
IMA status
  • Approved
IMA symbol
Mop
Discovered
1982
IMA approved
1982
Also known as
  • IMA1982-020
  • Mopungiet

Where it forms, where it's found

Geological setting

Oxidized zone of an antimony deposit.

Type locality
Green prospect
  1. Lake Mining District
  2. Churchill County
  3. Nevada
  4. USA

39.8700°, -118.7244°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Opaque
Colour
Colourless · white · creamy-white

May be colored tan to reddish-tan due to inclusions.

Streak
White
Tenacity
waxy
Cleavage
None Observed
Fracture
None observed

Optical

Optical type
Uniaxial (-)
Refractive index
1.605 – 1.614
Surface relief
Moderate
Principal indices
nω 1.614 · nε 1.605
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#140
Cell parameters
a = 7.994 Å · c = 7.859 Å
Morphology

Type material is pseudocubic and show the forms (001), (110) and (101). The crystal faces are invariably frosted or dull and have a wrinkled texture.

Type-locality form

Pseudocubic crystals, 0.2-0.3 mm on an edge, thickly encrusting fractures.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
49.34%
8OOxygenOxygen615.99995.994
38.90%
11NaSodiumSodium122.99022.990
9.31%
1HHydrogenHydrogen61.0086.048
2.45%
Total246.792100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-020
  • Mopungiet

In other languages

German
IMA 1982-020 · Mopungit
Italian
mopungite

Classification

Strunz
10th ed.

4.FC.15

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FCHydroxides with OH, without H2O; corner-sharing octahedraGroup
  • 4.FC.15MopungiteSpecies
Dana
8th ed.

06.03.07.04

  • 06Hydroxides and Oxides Containing HydroxylClass
  • 06.03X(OH)3Type
  • 06.03.07Wickmanite group (Tetragonal: P42/n)Group
  • 06.03.07.04MopungiteSpecies
CIM

24.1.1

  • 24Antimonates and AntimonitesClass
  • 24.1Antimonates and antimonites of Na, Cu or AgGroup
  • 24.1.1MopungiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1938Schrewelius, N. (1938): Röntgenuntersuchung der Verbindungen NaSb(OH)6, NaSb6, NaSbO3 und gleichartiger Stoffe. Zeitschrift für Anorganische und Allgemeine Chemie, 238, 241-254.
  2. 1985Dunn, Pete J., Ferraiolo, James A., Fleischer, Michael, Gobel, Volker, Grice, Joel D., Langley, Richard H., Shigley, James E., Vanko, David A., Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (11-12) 1329-1335
  3. 1985Williams, Sidney A. (1985) Mopungite, a New Mineral from Nevada. The Mineralogical Record, 16 (1) 73-74
  4. 2005(2005) Mopungite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2011Rintoul, Llew, Bahfenne, Silmarilly, Frost, Ray L. (2011) Single-crystal Raman spectroscopy of brandholzite Mg[Sb(OH)6]2•6H2O and bottinoite Ni[Sb(OH)6]2• 6H2O and the polycrystalline Raman spectrum of mopungite Na[Sb(OH)6]. Journal of Raman Spectroscopy, 42 (5). 1147-1153 doi:10.1002/jrs.2804DOI: 10.1002/jrs.2804
