Niobobaotite

Ba4(Ti2.5Fe2+1.5)Nb4Si4O28Cl
IMA status
  • Approved
  • Pending publication
IMA symbol
Nbao
IMA approved
2023
Also known as
  • IMA2022-127a
  • Niobobaotiet
  • UM1996-39-SiO:BaClFeNbTi

Where it forms, where it's found

Type locality
Bayan Obo deposit
  1. Bayan Obo mining district
  2. Baotou City
  3. Inner Mongolia
  4. China

41.7958°, 109.9694°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
brown to black
Streak
yellow
Tenacity
brittle
Cleavage
Very Good

(110)

Fracture
Irregular/Uneven
Density
4.684 g/cm³

Optical

Optical type
Uniaxial (+)
Pleochroism
Strong

ω = yellow and ɛ = brown.

UV response
none
Notes

the calculated average refractive index is 2.06(8), applying the Gladstone-Dale criterion

Crystallography

Crystal system
Tetragonal
Space group
#136
Cell parameters
a = 20.0264(6) Å · c = 5.9592(2) Å
Z
4
Parting
none
Type-locality form

columnar or platy, subhedral to anhedral grains ranging from approximately 20 to 80 μm

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium4137.327549.308
31.93%
8OOxygenOxygen2815.999447.972
26.04%
41NbNiobiumNiobium492.906371.624
21.61%
22TiTitaniumTitanium2.547.867119.667
6.96%
14SiSiliconSilicon428.085112.340
6.53%
26FeIronIron1.555.84583.767
4.87%
17ClChlorineChlorine135.45035.450
2.06%
Total1720.129100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • IMA2022-127a
  • Niobobaotiet
  • UM1996-39-SiO:BaClFeNbTi

In other languages

French
niobobaotite
German
IMA 2022-127a · Niobobaotit
Chinese
铌包头矿
Simplified Chinese
铌包头矿

Classification

Strunz
10th ed.

9.CE

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CENiobobaotiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. https://www.scienzenotizie.it/2023/10/10/scoperto-un-nuovo-minerale-con-caratteristiche-uniche-0273965
  2. 2023Bosi, Ferdinando, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2023) Newsletter 76. Mineralogical Magazine, 1-5 doi:10.1180/mgm.2023.89 DOI: 10.1180/mgm.2023.89
  3. 2026Ge, Xiangkun; Fan, Guang; Li, Ting; Wang, Tao; Deng, Liumin (2026) Niobobaotite, Ba4(Ti2.5Fe2+1.5)4Nb4(Si4O12)O16Cl, a new mineral species from the Bayan Obo REE-Nb-Fe deposit, Inner Mongolia, China. American Mineralogist. doi:10.2138/am-2025-10096DOI: 10.2138/am-2025-10096
