Obradovicite-NaCu

[Na2(H2O)17Cu(H2O)6][Mo8As2Fe3+3O34(OH)3]
IMA status
  • Approved
IMA symbol
Obr-NaCu
IMA approved
2011
Also known as
  • IMA2011-079
  • Obradoviciet-NaCu

Where it forms, where it's found

Geological setting

Oxidation zone of porphyry copper deposit.

Type locality
Chuquicamata Mine
  1. Chuquicamata District
  2. Calama
  3. El Loa Province
  4. Antofagasta
  5. Chile

-22.2894°, -68.9011°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellowish green
Streak
Very pale yellowish green
Tenacity
brittle
Cleavage
None Observed
Fracture
Splintery

Optical

Optical type
Biaxial (-) · 2V measured = 86°
Refractive index
1.79 – 1.805
Surface relief
High
Principal indices
nα 1.790 · nβ 1.798 · nγ 1.805
Pleochroism
Non-pleochroic
Dispersion
r > v, strong
UV response
None.
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#70
Cell parameters
a = 14.872(4) Å · b = 11.091(3) Å · c = 15.032(4) Å
Ratio a:b:c
1 : 0.746 : 1.011
Unit cell volume
2479.4 ų
Z
4
Morphology

Short bladed crystals, flattened on (001), elongated parallel to [010]. Size: Up to ~0.1 mm in length. Forms observed: (001), (110) and (101). The (001) are showing striations paralllel to [010]. Often double terminated.

Twinning

No twinning observed.

Type-locality form

Sugary aggregates intermixed with fragmented quartz crystals embedded in a porous boxwork of hematite and goethite.

Comment

Space group: Pnmb

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6015.999959.940
43.56%
42MoMolybdenumMolybdenum895.950767.600
34.83%
26FeIronIron355.845167.535
7.60%
33AsArsenicArsenic274.922149.844
6.80%
29CuCopperCopper163.54663.546
2.88%
1HHydrogenHydrogen491.00849.392
2.24%
11NaSodiumSodium222.99045.980
2.09%
Total2203.837100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-079
  • Obradoviciet-NaCu

In other languages

German
IMA 2011-079 · Obradovicit-NaCu
Italian
obradovicite-NaCu

Classification

Strunz
10th ed.

7.GB.45

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.45Obradovicite-NaCuSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011. CNMNC Newsletter No 11. Mineralogical Magazine, 75 (6) 2887-2893 doi:10.1180/minmag.2011.075.6.2887 DOI: 10.1180/minmag.2011.075.6.2887
  2. 2012Kampf, A. R., Mills, S. J., Rumsey, M. S., Dini, M., Birch, W. D., Spratt, J., Pluth, J. J., Steele, I. M., Jenkins, R. A., Pinch, W. W. (2012) The heteropolymolybdate family: structural relations, nomenclature scheme and new species. Mineralogical Magazine, 76 (5) 1175-1207 doi:10.1180/minmag.2012.076.5.09DOI: 10.1180/minmag.2012.076.5.09
  3. 2021(2021) Obradovicite-NaCu. Handbook of Mineralogy. Mineralogical Society of America
