Oldhamite

CaS
IMA status
  • Approved
  • Grandfathered
IMA symbol
Old
Discovered
1862
Also known as
  • Oldhamiet

Where it forms, where it's found

Geological setting

enstatite chondrite meteorite

Type locality
Bustee meteorite
  1. Gorakhpur
  2. Basti District
  3. Uttar Pradesh
  4. India

26.7500°, 82.7000°

64recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pale brown to dark brown

tarnishes strongly on exposure to humid air

Cleavage
Distinct/Good

(001)

Density
2.58 g/cm³

Optical

Optical type
Isotropic
Surface relief
Very high
Principal indices
n 2.137
Internal reflections
many
Notes

colorless to pale brown in transmitted light

Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 2.137

Crystallography

Crystal system
Isometric
Space group
Fm3m
Cell parameters
a = 5.6948 Å
Z
4
Type-locality form

single-crystal nodules, to 3 mm

Comment

on synthetic material

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium140.07840.078
55.56%
16SSulfurSulfur132.06032.060
44.44%
Total72.138100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Na
  • Fe
  • Cu

Synonyms

  • Oldhamiet

In other languages

German
Oldhamit
Spanish
Oldhamita
Italian
Oldhamite
Japanese
オルダム鉱

Classification

Strunz
10th ed.

2.CD.10

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CDWith Sn, Pb, Hg, etc.Group
  • 2.CD.10OldhamiteSpecies
CIM

3.4.2

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.4Sulphides etc. of Group II metals other than Hg (Mg, Ca, Zn, Cd)Group
  • 3.4.2OldhamiteSpecies

Group, growth & confusion

In the same group
5 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. Nestola, F. (2023): Commentary on “Oldhamite: a new link in upper mantle for C-O-S-Ca cycles and an indicator for planetary habitability”. National Science Review, DOI: 10.1093/nsr/nwad185
  2. 1870Maskelyne N S (1870) On the mineral constituents of meteorites. Proceedings of the Royal Society of London 18, 146-157
  3. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  4. 1968Larimer, John W (1968) An experimental investigation of oldhamite, CaS; and the petrologic significance of oldhamite in meteorites. Geochimica et Cosmochimica Acta, 32 (9) 965-982 doi:10.1016/0016-7037(68)90061-6DOI: 10.1016/0016-7037(68)90061-6
  5. 1969Binns, R.A. (1969): Oldhamite from the Hvittis meteorite. Mineralogical Magazine 37, 144-145.
