Örebroite

Mn2+6(Sb5+Fe3+)(SiO4)2O6
IMA status
  • Approved
IMA symbol
Öbr
IMA approved
1985
Also known as
  • IMA1985-039
  • Örebroiet
  • Retinostibian

Where it forms, where it's found

Type locality
Sjögruvan
  1. Grythyttan
  2. Hällefors
  3. Örebro County
  4. Sweden

59.6685°, 14.6079°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Opaque
Colour
dark brown · red brown
Streak
reddish brown
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
4.77 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.857 – 1.875
Surface relief
Very high
Principal indices
nω 1.857 · nε 1.875
Pleochroism
Weak
Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#75
Cell parameters
a = 8.183(7) Å · c = 4.756(9) Å
Z
2
Morphology

fine-grained, polycrystalline intergrowths and massive

Type-locality form

Massive and polycrystalline

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
25MnManganeseManganese654.938329.628
41.86%
8OOxygenOxygen1415.999223.986
28.45%
51SbAntimonyAntimony1121.760121.760
15.47%
14SiSiliconSilicon228.08556.170
7.13%
26FeIronIron155.84555.845
7.09%
Total787.389100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1985-039
  • Örebroiet
  • Retinostibian

In other languages

German
IMA 1985-039 · Örebroit
Italian
Örebroite · Orebroite-III · Orebroite-VIII

Classification

Strunz
10th ed.

9.AF.75

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.75ÖrebroiteSpecies
Dana
8th ed.

52.04.01.01

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.01Welinite groupGroup
  • 52.04.01.01ÖrebroiteSpecies
CIM

14.18.40

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.40ÖrebroiteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1986Dunn, Pete J., Peacor, Donald R., Erd, Richard C., Ramik, Robert A. (1986) Franciscanite and örebroite, two new minerals from California and Sweden, related to redefined welinite. American Mineralogist, 71 (11-12). 1522-1526
  2. 2001(2001) Örebroite. Handbook of Mineralogy. Mineralogical Society of America
