Welinite

Mn2+6(W6+◻)(SiO4)2O4(OH)2
IMA status
  • Approved
IMA symbol
Wln
Discovered
1966
IMA approved
1966
Also known as
  • IMA1966-002
  • Weliniet

Where it forms, where it's found

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
orange-red · deep red brown to reddish black
Streak
pale reddish brown
Tenacity
brittle
Cleavage
Distinct/Good

Poor to distinct on (001)

Density
4.47 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.864 – 1.88
Surface relief
Very high
Principal indices
nω 1.864 · nε 1.880
Notes

anomalously biaxial

Michel-Lévy diagramhighlighted lineδ = 0.0160
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]160 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation160 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#75
Cell parameters
a = 8.155(7) Å · c = 4.785(5) Å
Z
2
Morphology

As sections of crystals, to 2 cm.

Type-locality form

as fillings in fissures with other minerals cutting hausmannite ore

Comment

Originally assumed to be P63.

Crystal structure

Chemical composition

Impurities
  • Fe
  • Sb
  • H2O

Synonyms

  • IMA1966-002
  • Weliniet

In other languages

German
IMA 1966-002 · Welinit
Italian
Welinite · Welinite-III · Welinite-VIII
Chinese
硅钨锰矿

Classification

Strunz
10th ed.

9.AF.75

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.75WeliniteSpecies
Dana
8th ed.

52.04.01.02

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.04Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] and/or >[6] coordinationType
  • 52.04.01Welinite groupGroup
  • 52.04.01.02WeliniteSpecies
CIM

17.10.30

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.30WeliniteSpecies

Group, growth & confusion

In the same group
4 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1968Fleischer M (1968) New mineral names. American Mineralogist 53: 1064.
  2. 1968Moore, P. B. (1968) Welinite, a new mineral from Långban. Arkiv för Mineralogi och Geologi, 4 (5, nr 18). 407-411
  3. 1986Dunn, Pete J., Peacor, Donald R., Erd, Richard C., Ramik, Robert A. (1986) Franciscanite and örebroite, two new minerals from California and Sweden, related to redefined welinite. American Mineralogist, 71 (11-12). 1522-1526
  4. 2001(2001) Welinite. Handbook of Mineralogy. Mineralogical Society of America
