Parafransoletite

Ca3Be2(PO4)2(PO3OH)2 · 4H2O
IMA status
  • Approved
IMA symbol
Pfsl
Discovered
1989
IMA approved
1989
Also known as
  • IMA1989-049
  • Parafransoleit
  • Parafransoleita
  • +2 more

Where it forms, where it's found

Geological setting

Granite pegmatite.

Type locality
Tip Top Mine
  1. Fourmile
  2. Custer Mining District
  3. Custer County
  4. South Dakota
  5. USA

43.7156°, -103.6694°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · white
Streak
White
Tenacity
brittle
Cleavage
None Observed

'Even' fracture.

Density
2.54 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 33° · 2V calc = 34°
Refractive index
1.562 – 1.588
Surface relief
Moderate
Principal indices
nα 1.562 · nβ 1.564 · nγ 1.588
Dispersion
strong
Extinction
θ = 85°; ψ = –13°; φ = 98°.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.32 Å · b = 7.69 Å · c = 7.06 Å
Cell angles
α = 94.9 ° · β = 96.82 ° · γ = 101.86 °
Ratio a:b:c
1 : 1.051 : 0.964
Unit cell volume
385.48 ų
Z
1
Morphology

Thin individual spear-shaped blades, sheaf- and bowtie-like aggregates, and compact radial sprays. Similar to collinsite in appearance and notably distinct from fransoletite. Most crystals are composite with slightly rounded faces tapering to a pointed termination. Individual crystals are flattened on (010) and elongate parallel to [100]. Forms include (010), (011), (131), (131), and (144). Doubly terminated crystals are common and seemingly exhibit centrosymmetric development of crystal forms.

Twinning

Simple contact twinning on (010) is common.

Type-locality form

Thin individual spear-shaped blades up to 0.4 x 0.1 x 0.04 mm, as sheaf- and bowtie-like aggregates, and as compact radial sprays to 2 mm in diameter. It is similar to collinsite in appearance and notably distinct from fransoletite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
54.03%
15PPhosphorusPhosphorus430.974123.896
20.92%
20CaCalciumCalcium340.078120.234
20.30%
4BeBerylliumBeryllium29.01218.024
3.05%
1HHydrogenHydrogen101.00810.080
1.70%
Total592.214100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1989-049
  • Parafransoleit
  • Parafransoleita
  • Parafransoleite
  • Parafransoletiet

In other languages

German
IMA 1989-049 · Parafransoletit
Italian
Parafransoletite

Classification

Strunz
10th ed.

8.CA.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CAWith small and large/medium cationsGroup
  • 8.CA.05ParafransoletiteSpecies
Dana
8th ed.

40.05.02.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.05AXO4·xH2OType
  • 40.05.02— unnamed intermediate level —Group
  • 40.05.02.01ParafransoletiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1992Kampf, Anthony R., Dunn, Pete J., Foord, Eugene E. (1992) Parafransoletite, a new dimorph of fransoletite from the Tip Top Pegmatite, Custer, South Dakota. American Mineralogist, 77 (7-8) 843-847
  2. 1992Kampf, Anthony R. (1992) Beryllophosphate chains in the structures of fransoletite, parafransoletite, and ehrleite and some general comments on beryllophosphate linkages. American Mineralogist, 77 (7-8) 848-856
  3. 2005(2005) Parafransoletite. Handbook of Mineralogy. Mineralogical Society of America
