Polyadelphite

(Ca,Mn)3Fe3+2(SiO4)3
Discovered
1836

Where it forms, where it's found

Geological setting

Polymetallic sulphide-poor zinc deposit

Type locality
Franklin Mine
  1. Franklin
  2. Sussex County
  3. New Jersey
  4. USA

41.1158°, -74.5875°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Brown · red-brown · orange-brown · brown-black
Streak
white
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.8 g/cm³

Optical

Birefringence
0.000
Pleochroism
Non-pleochroic
UV response
Not fluorescent
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Morphology

Dodecahedral crystals with trapezohedral modifications

Parting
Poor to good parting is frequently observed
Type-locality form

Dark brown crystals and masses

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
28.53%
25MnManganeseManganese354.938164.814
24.49%
20CaCalciumCalcium340.078120.234
17.86%
26FeIronIron255.845111.690
16.60%
14SiSiliconSilicon328.08584.255
12.52%
Total672.981100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Literature, links & citation

Citations
  1. 1836Thomson, Thomas (1836) Outlines of Mineralogy, Geology and Mineral Analysis Vol. 1. Baldwin & Craddock. 734 pp.
  2. 1836Thomas Thomson (1836) System of Chemistry, v. 1, p. 154.
