Putnisite

SrCa4Cr3+8(CO3)8(SO4)(OH)16 · 25H2O
IMA status
  • Approved
IMA symbol
Pni
IMA approved
2012
Also known as
  • IMA2011-106
  • Putnisiet

Where it forms, where it's found

Type locality
Polar Bear peninsula
  1. Norseman
  2. Dundas Shire
  3. Western Australia
  4. Australia

-31.9158°, 121.8479°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Streak
Pink
Tenacity
brittle
Cleavage
Perfect

One excellent and two good cleavages parallel to (100), (010) and (001).

Fracture
Irregular/Uneven
Density
2.20 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.552 – 1.599
Surface relief
Moderate
Principal indices
nα 1.552 · nβ 1.583 · nγ 1.599
Pleochroism

Distinct: X pale bluish grey, Y pale purple, Z pale purple

Michel-Lévy diagramhighlighted lineδ = 0.0470
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]470 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation470 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pnma
Cell parameters
a = 15.351(3) Å · b = 20.421(4) Å · c = 18.270(4) Å
Ratio a:b:c
1 : 1.330 : 1.190
Unit cell volume
5727 ų
Z
4
Morphology

Pseudocubic crystals

Type-locality form

isolated pseudocubic crystals up to 0.5 mm in size in a matrix composed of quartz and a near amorphous Cr silicate

Comment

New structure type

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6915.9991103.931
56.25%
24CrChromiumChromium851.996415.968
21.20%
20CaCalciumCalcium440.078160.312
8.17%
6CCarbonCarbon812.01196.088
4.90%
38SrStrontiumStrontium187.62087.620
4.46%
1HHydrogenHydrogen661.00866.528
3.39%
16SSulfurSulfur132.06032.060
1.63%
Total1962.507100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Cl
  • Cu

Synonyms

  • IMA2011-106
  • Putnisiet

In other languages

French
putnisite
German
IMA 2011-106 · Putnisit
Spanish
Putnisita · Putnisite
Italian
putnisite
Portuguese
putnisita
Russian
Путнисит

Classification

Strunz
10th ed.

5.DB.40

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DBWith large and medium-sized cationsGroup
  • 5.DB.40PutnisiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 13. Mineralogical Magazine, 76 (3) 807-817 doi:10.1180/minmag.2012.076.3.26 DOI: 10.1180/minmag.2012.076.3.26
  2. 2014Elliott, P., Giester, G., Rowe, R., Pring, A. (2014) Putnisite, SrCa4Cr83+ (CO3)8SO4(OH)16·25H2O, a new mineral from Western Australia: description and crystal structure. Mineralogical Magazine, 78 (1) 131-144 doi:10.1180/minmag.2014.078.1.10DOI: 10.1180/minmag.2014.078.1.10
  3. 2015(2015) Putnisite. Handbook of Mineralogy. Mineralogical Society of America
