Radium-bearing Barite

(Ba,Ra)SO4
Also known as
  • Radian Barite
  • Radian Baryte
  • Radian baryte
  • +5 more
Variety of
Baryte
BaryteBa(SO4)

Where it forms, where it's found

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
White
Streak
White

Optical

Optical type
Biaxial (+) · 2V measured = 36 – 40° · 2V calc = 36 – 42°
Refractive index
1.634 – 1.648
Surface relief
Moderate
Principal indices
nα 1.634 – 1.637 · nβ 1.6355 – 1.638 · nγ 1.646 – 1.648
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0115
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]115 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation115 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
88RaRadiumRadium1226.000226.000
49.20%
56BaBariumBarium1137.327137.327
29.89%
8OOxygenOxygen415.99963.996
13.93%
16SSulfurSulfur132.06032.060
6.98%
Total459.383100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Radian Barite
  • Radian baryte
  • Radian Baryte
  • Radiobarit
  • Radiobarita
  • Radiobarite
  • Radiobaryt
  • Radiobaryte

Literature, links & citation

Citations
  1. 2001R.A. Zielinski, J.K. Otton and J.R. Budahn (2001): Use of radium isotopes to determine the age and origin of radioactive barite at oil-field production sites. Environ. Poll. 113, 299–309.
  2. 2007Ulrych, J., Adamovič, J., Žák, K., Frána, J., Řanda, Z., Langrová, A., Skála, R., Chvátal, M. (2007) Cenozoic “radiobarite” occurrences in the Ohře (Eger) Rift, Bohemian Massif: Mineralogical and geochemical revision. Chemie der Erde - Geochemistry, 67 (4). 301-312 doi:10.1016/j.chemer.2005.05.003DOI: 10.1016/j.chemer.2005.05.003
  3. 2008Grandia, F., Merino, J., Bruno, J. (2008): Assessment of the radium-barium co-precipitation and its potential influence on the solubility of Ra in the near-field. SKB Technical Report TR-08-07.
  4. 2020Jirásek, Jakub, Matýsek, Dalibor, Alexa, Petr, Osovský, Michal, Uhlář, Radim, Sivek, Martin (2020) High Specific Activity of Radium Isotopes in Baryte from the Czech Part of the Upper Silesian Basin—An Example of Spontaneous Mine Water Treatment. Minerals, 10 (2) 103 doi:10.3390/min10020103 DOI: 10.3390/min10020103
