Rinmanite

Mg2Fe4Zn2Sb2O14(OH)2
IMA status
  • Approved
IMA symbol
Rnm
IMA approved
2000
Also known as
  • IMA2000-036
  • Rinmaniet

Where it forms, where it's found

Geological setting

Skarn deposit

Type locality
Garpenberg Norra Mine
  1. Garpenberg
  2. Hedemora
  3. Dalarna County
  4. Sweden

60.3325°, 16.2278°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Submetallic
Transparency
Translucent
Colour
Black · (translucent dark red)
Streak
Brown
Tenacity
brittle
Cleavage
Very Good

Well developed (100)

Fracture
Splintery
Density
5.13 g/cm³

Optical

Optical type
Uniaxial (-)
Pleochroism
Visible

O = dark red, E = orange red

Optical colour
Gray
Anisotropism
Moderate
Bireflectance
Weak
Internal reflections
Orange red
Tropism
Anisotropic
Reflectance R%
(12.2,13.6) 460, (11.8,12.9) 540, (11.7,12.7) 580, (11.4,12.3) 640
Reflected-light panel
11.8 %anisotropic · dual curve
Specimen sRGB 128, 89, 48
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak
Anisotropism
Moderate
Reflected colour
Gray
Internal reflections
Orange red

Crystallography

Crystal system
Hexagonal
Space group
#104
Cell parameters
a = 5.9889(4) Å · c = 9.353(1) Å
Unit cell volume
290.53 ų
Z
1
Morphology

Euhedral, prismatic crystals, elongate [001] to 0.5 mm.

Twinning

Common penetration twinning.

Type-locality form

Tiny flat prisms intergrown up to 0.5 mm length intergrown with franklinite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
28.31%
51SbAntimonyAntimony2121.760243.520
26.93%
26FeIronIron455.845223.380
24.70%
30ZnZincZinc265.380130.760
14.46%
12MgMagnesiumMagnesium224.30548.610
5.38%
1HHydrogenHydrogen21.0082.016
0.22%
Total904.270100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2000-036
  • Rinmaniet

In other languages

German
IMA 2000-036 · Rinmanit
Spanish
Rinmanita
Italian
Rinmanite

Classification

Strunz
10th ed.

4.CB.40

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.40RinmaniteSpecies

Group, growth & confusion

In the same group
1 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 2001Holtstam, D., Gatedal, K., Soderberg, K., Norrestam, R. (2001) Rinmanite, Zn2Sb2Mg2Fe4O14(OH)2, a new mineral species with a nolanite-type structure from the Garpenberg Norra mine, Dalarna, Sweden. The Canadian Mineralogist, 39 (6) 1675-1683 doi:10.2113/gscanmin.39.6.1675 DOI: 10.2113/gscanmin.39.6.1675
  2. 2002Mandarino, Joseph A. (2002) New minerals. The Canadian Mineralogist, 40 (4) 1215-1234 doi:10.2113/gscanmin.40.4.1215 DOI: 10.2113/gscanmin.40.4.1215
  3. 2003Jambor, J.L., Roberts, A.C. (2003) New mineral names. American Mineralogist: 88: 251-255.
  4. 2021(2021) Rinmanite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2024Biagioni, C., Mugnaioli, E., Lorenzon, S., Mauro, D., Musetti, S., Sejkora, J., Belmonte, D., Demitri, N., Dolníček, Z. (2024) Nannoniite, IMA 2024-010, in IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 80. European Journal of Mineralogy, 36 (4). 599-604 doi:10.5194/ejm-36-599-2024DOI: 10.5194/ejm-36-599-2024
