Nolanite

V3+8Fe3+2O14(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Nol
Discovered
1955
Also known as
  • Nolaniet

Where it forms, where it's found

Geological setting

Hydrothermal.

Type locality
Ace deposit
  1. Eldorado Mining & Refining Ltd. mines
  2. Beaverlodge Lake area
  3. Saskatchewan
  4. Canada

59.4667°, -108.3667°

19recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Black

In thin splinters it is slightly translucent.

Streak
Brownish black
Density
4.65 g/cm³

Optical

Optical type
Uniaxial
Pleochroism
Visible

Dark brown to deep blue.

Anisotropism
Moderate; light to dark gray
Tropism
Anisotropic
Reflectance R%
(11.,012.7) 470, (11.8,13.5) 546, (12.3,14.0) 589
Notes

Plates with the c crystallographic axis normal to the surface are virtually isotropic, but sections containing the a and c axes are markedly anisotropic with parallel extinction.

Reflected-light panel
11.7 %anisotropic · dual curve
Specimen sRGB 133, 89, 44
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Moderate; light to dark gray

Crystallography

Crystal system
Hexagonal
Space group
#114
Cell parameters
a = 5.870(27) Å · c = 9.275(20) Å
Z
1
Morphology

Minute hexagonal plates and radiating crusts. Forms include c(0001), m(1010), and p(1011).

Type-locality form

Concentrations of discrete subhedral to euhedral hexagonal plates from 10 to 20 microns in diameter and masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
23VVanadiumVanadium850.942407.536
52.43%
8OOxygenOxygen1615.999255.984
32.94%
26FeIronIron255.845111.690
14.37%
1HHydrogenHydrogen21.0082.016
0.26%
Total777.226100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Nolaniet

In other languages

German
Nolanit
Italian
Nolanite

Classification

Strunz
10th ed.

4.CB.40

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.40NolaniteSpecies
Dana
8th ed.

04.06.07.01

  • 04Simple OxidesClass
  • 04.06MiscellaneousType
  • 04.06.07— unnamed intermediate level —Group
  • 04.06.07.01NolaniteSpecies
CIM

7.12.20

  • 7Oxides and HydroxidesClass
  • 7.12Oxides of V, Nb and TaGroup
  • 7.12.20NolaniteSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1957Robinson, S. C., Evans, H. T., Schaller, W. T., Fahey, J. J. (1957) Nolanite, a new iron-vanadium mineral from Beaverlodge, Saskatchewan. American Mineralogist, 42 (9-10) 619-628
  2. 1958Hanson, A. W. (1958) The crystal structure of nolanite. Acta Crystallographica, 11 (10) 703-709 doi:10.1107/s0365110x58001894DOI: 10.1107/s0365110x58001894
  3. 1967Taylor, Charles M., Radtke, Arthur S. (1967) New occurrence and data of nolanite. American Mineralogist, 52 (5-6) 734-743
  4. 1983Gatehouse, Bryan M., Grey, Ian E., Nickel, Ernest H. (1983) The crystal chemistry of nolanite, (V,Fe,Ti,Al)10O14(OH)2, from Kalgoorlie, Western Australia. American Mineralogist, 68 (7-8) 833-839
  5. 1986Wu Shengyang, Wang Desheng (1986) First Occurrence of Nolanite in China. Acta Petrologica Et Mineralogica, 5(1), 68-74.
