Rösslerite

Mg(AsO3OH) · 7H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Also known as
  • Roesslerite
  • Rössleriet

Where it forms, where it's found

Geological setting

Oxidized zones of arsenical ore bodies.

Type locality
"Im Lochborn" Copper mine
  1. Bieber
  2. Biebergemünd
  3. Main-Kinzig-Kreis
  4. Darmstadt
  5. Hesse
  6. Germany

50.1408°, 9.3619°

19recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless to white · faint tints · colorless in transmitted light.
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

On (111), poor.

Density
1.943 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 28°
Refractive index
1.488 – 1.507
Surface relief
Low
Principal indices
nα 1.488 · nβ 1.507 · nγ 1.1.510
Birefringence
0.022
Pleochroism
Non-pleochroic
Dispersion
r > v
Extinction
Inclined. Previously measured optics were apparently made on the wrong species or on material that was a more hydrated material.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 6.692 Å · b = 25.744 Å · c = 11.538 Å
Cell angles
β = 95.15 °
Ratio a:b:c
1 : 3.847 : 1.724
Z
8
Morphology

Well-formed crystals rare, small, short prismatic [001]. Fine-grained crusts; hair-like at times. Artificial crystals are tabular (010).

Comment

Zeit. Krist. 137:194 (1973) structure

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
60.62%
33AsArsenicArsenic174.92274.922
25.80%
12MgMagnesiumMagnesium124.30524.305
8.37%
1HHydrogenHydrogen151.00815.120
5.21%
Total290.336100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Roesslerite
  • Rössleriet

In other languages

German
Rösslerit
Italian
Rösslerite

Classification

Strunz
10th ed.

8.CE.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CEWith only medium-sized cations, RO4:H2O about 1:2.5Group
  • 8.CE.20RössleriteSpecies
Dana
8th ed.

39.01.09.01

  • 39Hydrated Acid Phosphates, Arsenates and VanadatesClass
  • 39.01A[HXO4]·xH2OType
  • 39.01.09— unnamed intermediate level —Group
  • 39.01.09.01RössleriteSpecies
CIM

20.2.3

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.2Arsenates of Be, Mg, Ca or BaGroup
  • 20.2.3RössleriteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1861Blum, R. (1861) Rösslerit, ein neues Mineral. Jahresbericht der Wetterauischen Gesellschaft für die Gesammte Naturkunde zu Hanau, Naturhistorische Abhandlungen: 1861: 32-36.
  2. 1861Blum, R. (1861) Rösslerit, ein neues Mineral. Neues Jahrbuch für Mineralogie, Geognosie, Geologie und Petrefakten-Kunde: 1861: 334-335.
  3. 1867Tschermak (1867) Königliche Akademie der Wissenschaften, Vienna, Ber.: 56: 824.
  4. 1880Schrauf, A. (1880) Ueber Arsenate von Joachimsthal. 1. Mixit, ein neues Kupferwismuthhydroarsenat. 2. Wapplerit. 3. Pharmakolith. Zeitschrift für Kristallographie, 4 (1). 277-285 doi:10.1524/zkri.1880.4.1.277DOI: 10.1524/zkri.1880.4.1.277
  5. 1882Haushofer (1882) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 7: 259 (artif. crystals).
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Rösslerite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/rosslerite-3470},
  note      = {Accessed 2026-05-11}
}
