Rucklidgeite

PbBi2Te4
IMA status
  • Approved
IMA symbol
Ruk
Discovered
1975
IMA approved
1975
Also known as
  • IMA1975-029
  • Rucklidgeiet

Where it forms, where it's found

Geological setting

Hydrothermal.

Type locality
Sotk gold mine
  1. Sotk
  2. Gegharkunik Province
  3. Armenia

40.2330°, 45.9680°

73recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver-white
Streak
Lead-gray
Tenacity
flexible
Cleavage
Perfect

Perfect on the pinacoid and average on the rhombohedron.

Said to be brittle, but easily split into flexible but inelastic plates. Fractures easily.

Density
7.739 g/cm³

Optical

Pleochroism
Weak

Very weak in air, noticeable in oil.

Optical colour
White with a very weak rose tint. Creamy relative to volynskite but pale rose relative to altaite.
Anisotropism
Distinct, reddish-brown to bluish-grey
Tropism
Anisotropic
Reflectance R%
(62.0, 59.8) 440, (62.7, 60.3) 480, (63.3, 60.5) 520, (63.8, 60.8) 560, (64.1, 61.0) 600, (65.0, 61.9) 640, (65.9, 62.9) 680, (66.2, 63.1) 700
Reflected-light panel
64.1 %anisotropic · dual curve
Specimen sRGB 255, 193, 107
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Distinct, reddish-brown to bluish-grey
Reflected colour
White with a very weak rose tint. Creamy relative to volynskite but pale rose relative to altaite.

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 4.422 Å · c = 41.49 Å
Z
3
Type-locality form

Very similar to tellurobismuthite, occurring as silver-white foliated aggregates intergrown with gold (9 x 13 mm), and as tabular grains (to 0.5 mm) of different orientations bordering arsenopyrite and boulangerite in dolomite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium4127.600510.400
44.95%
83BiBismuthBismuth2208.980417.960
36.81%
82PbLeadLead1207.200207.200
18.24%
Total1135.560100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ag
  • Sb

Synonyms

  • IMA1975-029
  • Rucklidgeiet

In other languages

German
IMA 1975-029 · Rucklidgeit
Italian
Rucklidgeite

Classification

Strunz
10th ed.

2.GC.40c

  • 2Sulfides and SulfosaltsClass
  • 2.GSulfarsenites, sulfantimonites, sulfbismuthitesDivision
  • 2.GCPoly-sulfarsenitesGroup
  • 2.GC.40cRucklidgeiteSpecies
Dana
8th ed.

02.06.02.07

  • 02SulfidesClass
  • 02.06AmBnXp, with (m+n):p = 4:3Type
  • 02.06.02Joseite Group (Trigonal: R-3m)Group
  • 02.06.02.07RucklidgeiteSpecies
CIM

3.7.38

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.7Sulphides etc. of V, As, Sb and BiGroup
  • 3.7.38RucklidgeiteSpecies

Group, growth & confusion

In the same group
7 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1969Rucklidge, J. (1969) Frohbergite, montbrayite and a new Pb-Bi telluride. The Canadian Mineralogist: 9: 709-715.
  2. 1970Zhukova, T.B., Zaslavskii, A.I. (1970) X-ray structure determination of PbBi4Te7. Zhurnal Strukturnoi Khimii: 11: 462-468.
  3. 1977Zav'yalov, Ye.N., Begizov, V.D. (1977) Rucklidgeite, (Bi,Pb)3Te4, a new mineral from from the Zod and Kochkar gold ore deposits. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 106(1): 62-68.
  4. 1977Zav'yalov, Ye.N., Begizov, V.D. (1977) Rucklidgeite, (Bi,Pb)3Te4, a new mineral from from the Zod and Kochkar gold ore deposits. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 106(1): 62-68. (in Russian)
  5. 1977Zav'yalov, Ye.N., Begizov, V.D. (1977) Rucklidgeite, (Bi, Pb)3Te4, a new mineral from the Zod and Kochkar gold-ore deposits. International Geology Review, 19 (12) 1451-1456 doi:10.1080/00206817709471159DOI: 10.1080/00206817709471159
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Rucklidgeite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/rucklidgeite-3474},
  note      = {Accessed 2026-05-11}
}
