Saddlebackite

Pb2Bi2Te2S3
IMA status
  • Approved
IMA symbol
Sdd
Also known as
  • IMA1994-051
  • Saddlebackiet

Where it forms, where it's found

Type locality
Boddington Mine
  1. Bannister
  2. Boddington Shire
  3. Western Australia
  4. Australia

-32.7563°, 116.3479°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Grey · but often appears black due to specular reflection
Streak
Blackish
Tenacity
sectile
Cleavage
Perfect

0001 cleavage faces.

Fracture
Irregular/Uneven
Density
7.61 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
Greyish-white
Anisotropism
Grey to yellowish - brownish grey
Bireflectance
Weakly
Internal reflections
Slight pinkish tint is sometimes observed due, possibly, to internal reflections
Tropism
Anisotropic
Reflectance R%
(55.8,52.6) 400, (55.8,53.0) 420, (55.8,53.4) 440, (55.6,53.8) 460, (55.2,54.1) 480, (54.7,54.3) 500, (54.2,54.4) 520, (53.5,54.5) 540, (52.8,54.5) 560, (52.2,54.5) 580, (51.8,54.4) 600, (51.3,54.3) 620, (51.0,54.2) 640, (50.7,54.1) 660, (50.5,53.9) 680, (50.3,53.8) 700
Reflected-light panel
53.2 %anisotropic · dual curve
Specimen sRGB 251, 179, 103
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weakly
Anisotropism
Grey to yellowish - brownish grey
Reflected colour
Greyish-white
Internal reflections
Slight pinkish tint is sometimes observed due, possibly, to internal reflections

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 4.230(4) Å · c = 33.43(2) Å
Z
2
Type-locality form

Millimetre-sized aggregates, platy or flaky habit.

Comment

Satisfactory single crystal X-ray diffraction patterns could not be obtained, possibly due to stacking faults or mechanical deformation of the cleavage fragments.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth2208.980417.960
35.31%
82PbLeadLead2207.200414.400
35.01%
52TeTelluriumTellurium2127.600255.200
21.56%
16SSulfurSulfur332.06096.180
8.12%
Total1183.740100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1994-051
  • Saddlebackiet

In other languages

German
IMA 1994-051 · Saddlebackit
Italian
Saddlebackite

Classification

Strunz
10th ed.

2.GC.40d

  • 2Sulfides and SulfosaltsClass
  • 2.GSulfarsenites, sulfantimonites, sulfbismuthitesDivision
  • 2.GCPoly-sulfarsenitesGroup
  • 2.GC.40dSaddlebackiteSpecies
Dana
8th ed.

02.02.07

  • 02SulfidesClass
  • 02.02AmBnXp, with (m+n):p = 3:1Type
  • 02.02.07— unnamed intermediate level —Group
  • 02.02.07SaddlebackiteSpecies

Group, growth & confusion

In the same group
7 members

Literature, links & citation

Citations
  1. 1997Clarke, R.M. (1997) Saddlebackite, Pb2Bi2Te2S3, a new mineral species from the Boddinton gold deposit, Western Australia. Australian Journal of Mineralogy: 3: 119-124.
  2. 1998Mandarino, Joseph A. (1998) Abstracts of New Mineral Descriptions. The Mineralogical Record, 29 (5) 467-479
  3. 1998Jambor, John L.; Kovalenker, Vladimir A.; Roberts, Andrew C. (1998) New mineral names. American Mineralogist, 83. 1117-1121
  4. 2005(2005) Saddlebackite. Handbook of Mineralogy. Mineralogical Society of America
