Rutheniridosmine

(Ir,Os,Ru)
IMA status
  • Approved
IMA symbol
Rir
Discovered
1936

Where it forms, where it's found

Type locality
Horokanai placer
  1. Uryugawa
  2. Uryu District
  3. Kamikawa Subprefecture
  4. Hokkaidō Prefecture
  5. Japan
49recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver-white

Optical

Pleochroism
Weak

Weak to absent

Optical colour
white with a bluish gray tinge.
Anisotropism
Weak to moderate; may show wavy extinction, colors tinged with orange.
Tropism
Anisotropic

Crystallography

Crystal system
Hexagonal
Space group
P63/mmc
Cell parameters
a = 2.726(2) Å · c = 4.326(3) Å
Z
2
Twinning

Very fine lamellar twinning, but nearly isotropic

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
77IrIridiumIridium1192.217192.217
39.76%
76OsOsmiumOsmium1190.230190.230
39.34%
44RuRutheniumRuthenium1101.070101.070
20.90%
Total483.517100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Pt
  • Pd
  • Rh
  • Fe
  • Ni

In other languages

German
Rutheniridosmin
Italian
Ruteniridosmina · Rutheniridosmine
Japanese
ルテノイリドスミン

Classification

Strunz
10th ed.

1.AF.05

  • 1ElementsClass
  • 1.AMetals and Intermetallic AlloysDivision
  • 1.AFPlatinum group elementsGroup
  • 1.AF.05RutheniridosmineSpecies
Dana
8th ed.

01.02.02.03

  • 01Native Elements and AlloysClass
  • 01.02Platinum Group Metals and AlloysType
  • 01.02.02Osmium group (Space Group P63/mmc)Group
  • 01.02.02.03RutheniridosmineSpecies

Group, growth & confusion

Often grow together
9 minerals

Literature, links & citation

Citations
  1. 1973Harris, D. C., Cabri, L. J. (1973) The nomenclature of the natural alloys of osmium, iridium and ruthenium based on new compositional data of alloys from world-wide occurrences. The Canadian Mineralogist, 12 (2) 104-112
  2. 1975American Mineralogist (1975): 60: 946 (abstract).
  3. 1981Cabri, L.J., Ed. (1981) Platinum group elements: mineralogy, geology, recovery. Canadian Institute of Min. & Met., Special Volume 23: 134–135.
  4. 1991Harris, D. C., Cabri, L. J. (1991) Nomenclature of platinum-group-element alloys: review and revision. The Canadian Mineralogist, 29 (2) 231-237
  5. 1993Criddle, A. J., Stanley, C. J. (1993) Data file. In Quantitative Data File for Ore Minerals. Springer Netherlands. p.1-635. doi:10.1007/978-94-011-1486-8_1DOI: 10.1007/978-94-011-1486-8_1
