Satterlyite

(Fe2+,Mg,Fe3+)12(PO3OH)(PO4)5(OH,O)6
IMA status
  • Approved
IMA symbol
Sly
Discovered
1976
IMA approved
1976
Also known as
  • IMA1976-056
  • Satterlyiet

Where it forms, where it's found

Geological setting

Nodules in shales.

Type locality
Big Fish River
  1. Dawson mining district
  2. Yukon
  3. Canada

68.4738°, -136.4874°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light brown · pale yellow
Streak
Light yellow
Cleavage
None Observed
Density
3.68 g/cm³

Optical

Optical type
Uniaxial (-) · 2V measured = 10 – 20°
Refractive index
1.719 – 1.721
Surface relief
High
Principal indices
nω 1.721 · nε 1.719
Pleochroism
Visible

O = pale yellow; E = brownish yellow.

UV response
none
Notes

Absorption: E > O.

Michel-Lévy diagramhighlighted lineδ = 0.0020
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]20 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation20 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#95
Cell parameters
a = 11.35 Å · c = 5.04 Å
Z
6
Morphology

Grains, elongated along [0001].

Type-locality form

Grains up to 1x1x40 mm elongate parallel to [0001] in radiating aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron2455.8451340.280
55.83%
8OOxygenOxygen3615.999575.964
23.99%
12MgMagnesiumMagnesium1224.305291.660
12.15%
15PPhosphorusPhosphorus630.974185.844
7.74%
1HHydrogenHydrogen71.0087.056
0.29%
Total2400.804100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-056
  • Satterlyiet

In other languages

French
satterlyite
German
IMA 1976-056 · Satterlyit
Spanish
satterlyite
Italian
Satterlyite

Classification

Strunz
10th ed.

8.BB.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BBWith only medium-sized cations, (OH, etc.):RO4 about 1:1Group
  • 8.BB.20SatterlyiteSpecies
Dana
8th ed.

41.06.04.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.06A2(XO4)ZqType
  • 41.06.04Satterlyite GroupGroup
  • 41.06.04.01SatterlyiteSpecies
CIM

19.14.10

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.10SatterlyiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1978Mandarino, J. A., Sturman, B. D., Corlett, M. I. (1978) Satterlyite, a new hydroxyl-bearing ferrous phosphate from the Big Fish River area, Yukon Territory. The Canadian Mineralogist, 16 (3) 411-413
  2. 1979Fleischer, Michael, Chao, George Y., Mandarino, J. A. (1979) New mineral names. American Mineralogist, 64 (5-6) 652-659
  3. 2002Kolitsch, Uwe, Andrut, Michael, Giester, Gerald (2002) Satterlyite, (Fe,Mg)12(PO3OH)(PO4)5(OH,O)6: crystal structure and infrared absorption spectra. European Journal of Mineralogy, 14 (1) 127-133 doi:10.1127/0935-1221/2002/0014-0127 DOI: 10.1127/0935-1221/2002/0014-0127
  4. 2003Chandrasekhar, A.V., Ramanaiah, M.Venkata, Reddy, B.J., Reddy, Y.P., Rao, P.S., Ravikumar, R.V.S.S.N. (2003) Optical and EPR studies of iron bearing phosphate minerals: satterlyite and gormanite from Yukon Territory, Canada. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 59 (9) 2115-2121 doi:10.1016/s1386-1425(03)00017-9DOI: 10.1016/s1386-1425(03)00017-9
  5. 2005(2005) Satterlyite. Handbook of Mineralogy. Mineralogical Society of America
