Alluaudite

◻NaMnFe3+2(PO4)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ald
Discovered
1848
Also known as
  • Alluaudiet
  • Alluauditt
  • Ferri-alluaudite
  • +4 more

Where it forms, where it's found

Geological setting

Very common in granite pegmatites, formed by sodium metasomatism of triphylite–lithiophilite, heterosite–purpurite, or ferrisicklerite; in phosphatic nodules in shales.

Type locality
Varuträsk
  1. Skellefteå
  2. Västerbotten County
  3. Sweden

64.8008°, 20.7411°

80recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dirty yellow to brownish yellow · grayish green · surficially dull greenish black · brownish black · black · when altered

yellow to yellow-green in transmitted light

Streak
Brownish yellow
Cleavage
Distinct/Good

On (100) and (010) (110) , good.

Density
3.4 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 50 – 90° · 2V calc = 78°
Refractive index
1.782 – 1.835
Surface relief
Very high
Principal indices
nα 1.782 · nβ 1.802 · nγ 1.835
Pleochroism
Weak

X = pale olive-green, straw-yellow to greenish yellow; Z = pale olive-greenish to brownish yellow.

Dispersion
r > v moderate
Michel-Lévy diagramhighlighted lineδ = 0.0530
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]530 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation530 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 11.03 Å · b = 12.53 Å · c = 6.4 Å
Cell angles
β = 97.57 °
Ratio a:b:c
1 : 1.136 : 0.580
Z
4
Morphology

Crystals platy to fibrous, to 1 cm; usually radiating fibrous, in nodular aggregates; granular, massive.

Twinning

Twinning: Polysynthetic, with (101) as composition plane, seen in thin section.

Type-locality form

Crystals platy to fibrous, to 1 cm; usually radiating fibrous, in nodular aggregates; granular, massive

Crystal structure

Synonyms

  • Alluaudiet
  • Alluauditt
  • Ferri-alluaudite
  • Hühnerkobelite
  • Lemn‪äsite
  • Mangan-alluaudite
  • Mn-alluaudite

In other languages

French
Alluaudite
German
Alluaudit
Spanish
Alluaudita
Italian
alluaudite
Russian
Алюодит
Arabic
ألوديت

Classification

Strunz
10th ed.

8.AC.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.10AlluauditeSpecies
Dana
8th ed.

38.02.03.06

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.02(AB)5(XO4)3Type
  • 38.02.03Alluaudite-Wyllieite Group (Alluaudite Subgroup)Group
  • 38.02.03.06AlluauditeSpecies
CIM

19.12.28

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.28AlluauditeSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1848Damour A A (1848) Sur un nouveau phosphate de fer, de manganèse et de soude, l´alluaudite, trouvé dans le département de la Haute-Vienne. Annales des Mines 13, 341-350
  2. 1937Quensel (1937) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 59: 77.
  3. 1939Pehrman (1939) Acta Ac. Aboensis, Math. Phys.: 12: no. 6. [as Lemn‪äsite]
  4. 1940Quensel (1940) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 62: 300.
  5. 1941Mason (1941) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 63: 117.
