Schäferite

(NaCa2)Mg2(VO4)3
IMA status
  • Approved
IMA symbol
Sfr
IMA approved
1997
Also known as
  • IMA1997-048
  • Schäferiet

Where it forms, where it's found

Geological setting

Silicate-rich xenolith in leucite tephrite lava.

Type locality
Caspar quarry
  1. Ettringen
  2. Vordereifel
  3. Mayen-Koblenz
  4. Rhineland-Palatinate
  5. Germany

50.3525°, 7.2335°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Orange-red
Streak
Yellow
Cleavage
None Observed
Fracture
Conchoidal
Density
3.40 g/cm³

Optical

Optical type
Isotropic
UV response
Not fluorescent
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Space group
#225
Cell parameters
a = 12.427(2) Å
Morphology

Mainly (112), with (100) and (110) also present.

Type-locality form

Orange-red, euhedral crystals, up to 0.15 mm across.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
38.66%
23VVanadiumVanadium350.942152.826
30.78%
20CaCalciumCalcium240.07880.156
16.14%
12MgMagnesiumMagnesium224.30548.610
9.79%
11NaSodiumSodium122.99022.990
4.63%
Total496.570100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1997-048
  • Schäferiet

In other languages

German
IMA 1997-048 · Schäferit
Italian
Schäferite

Classification

Strunz
10th ed.

8.AC.25

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.25SchäferiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1999Krause, W., Blass, G., Effenberger, H. (1999) Schäferite, a new vanadium garnet from the Bellerberg volcano, Eifel, Germany. Neues Jahrbuch für Mineralogie - Monatshefte, 1999 (3) 123-124
  2. 2003Nakatsuka, Akihiko, Ikuta, Yasuaki, Yoshiasa, Akira, Iishi, Kazuake (2003) Vanadate garnet, Ca2NaMg2V3O12. Acta Crystallographica Section C Crystal Structure Communications, 59 (12). i133-i135 doi:10.1107/s0108270103023035DOI: 10.1107/s0108270103023035
  3. 2023(2023) Schäferite. Handbook of Mineralogy. Mineralogical Society of America
