Schapbachite

Ag0.4Pb0.2Bi0.4S
IMA status
  • Approved
  • Grandfathered
IMA symbol
Spb
Discovered
2004
IMA approved
1982
Also known as
  • Schapbachiet
  • Wismutsilbererz

Where it forms, where it's found

Type locality
Silberbrünnle Mine
  1. Gengenbach
  2. Gengenbach
  3. Ortenaukreis
  4. Freiburg Region
  5. Baden-Württemberg
  6. Germany

48.4375°, 8.0844°

30recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Dark grey
Streak
Black
Tenacity
brittle
Cleavage
None Observed
Density
7.05 g/cm³

Optical

Optical type
Isotropic
Reflectance R%
(45.19) 470, (44.73) 546, (44.32) 589, (43.94) 650
Reflected-light panel
44.5 %isotropic · single curve
Specimen sRGB 235, 165, 92
White reference100 % reflector under same lamp

Crystallography

Crystal system
Isometric
Space group
Fm3m
Cell parameters
a = 5.703 Å
Z
2
Type-locality form

Anhedral and reach about 0.3 mm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth0.4208.98083.592
41.75%
47AgSilverSilver0.4107.86843.147
21.55%
82PbLeadLead0.2207.20041.440
20.69%
16SSulfurSulfur132.06032.060
16.01%
Total200.239100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Schapbachiet
  • Wismutsilbererz

In other languages

German
Schapbachit
Italian
Schapbachite

Classification

Strunz
10th ed.

2.JA.15

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JAGalena derivatives with little or no PbGroup
  • 2.JA.15SchapbachiteSpecies
CIM

5.2.18

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.2Sulpharsenites etc. of AgGroup
  • 5.2.18SchapbachiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. Ramdohr, P. (1980): The ore minerals and their intergrowth. 2nd ed. (English ed. of the 4th German edition, with additions and corrections by the author), Pergamon Press, Oxford, 1205 pp.
  2. 1853Kenngott, A. (1853) Schapbachit. in Das Mohs'sche Mineralsystem, dem gegenwärtigen Standpunkte der Wissenschaft gemäss, Verlag und Druck von Carl Gerold & Sohn. (Wien) 118-118.
  3. 1863Sandberger, F. (1863) Jahresbuch fur Mineralogie, p. 797.
  4. 1877Rammelsberg, C. (1877) Ueber Nephelin, Monacit und Silberwismuthglanz. Zeitschrift der Deutschen Geologischen Gesellschaft, 29, 77-81.
  5. 1882Sandberger, F. (1882): Untersuch. Erzgadhge, 1, 90.
