Silvialite

Ca4Al6Si6O24(SO4)
IMA status
  • Approved
IMA symbol
Slv
IMA approved
1998
Also known as
  • IMA1998-010
  • Silvialiet
  • Silvialit

Where it forms, where it's found

Geological setting

mafic and ultramafic xenoliths from the lower crust or upper mantle

Granulite facies metamorphic rocks

Type locality
Cone No. 32
  1. Cook Shire
  2. Queensland
  3. Australia

-18.2500°, 144.7500°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
White · slightly yellowish
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

parallel to (100)

Fracture
Conchoidal
Density
2.75 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.558 – 1.585
Surface relief
Moderate
Principal indices
nω 1.585 · nε 1.558
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0270
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]270 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation270 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#135
Cell parameters
a = 12.160(3) Å · c = 7.560(1) Å
Z
2
Comment

Contains disordered carbonate and sulfate groups along the fourfold axis.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
46.15%
14SiSiliconSilicon628.085168.510
17.36%
13AlAluminiumAluminium626.982161.892
16.68%
20CaCalciumCalcium440.078160.312
16.51%
16SSulfurSulfur132.06032.060
3.30%
Total970.746100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-010
  • Silvialiet
  • Silvialit

In other languages

French
Silvialite
German
IMA 1998-010 · Silvialith
Italian
Silvialite

Classification

Strunz
10th ed.

9.FB.15

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FBTektosilicates with additional anionsGroup
  • 9.FB.15SilvialiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. Neues Jahrbuch für Mineralogie, Geologie und Paläontologie: 39: 79-125.
  2. 1914Brauns, R. (1914) Skapolithfüuhrende Auswüurflinge aus dem Laacher Seegebiet. Neues Jahrbuch füur Mineralogie, Geologie und Paläaeontologie: 39: 79-125.
  3. 1999Teertstra, D. K., Schindler, M., Sherriff, B. L., Hawthorne, F. C. (1999) Silvialite, a new sulfate-dominant member of the scapolite group with an Al-Si composition near the 14/mP42/n phase transition. Mineralogical Magazine, 63 (3) 321-329 doi:10.1180/002646199548547 DOI: 10.1180/002646199548547
  4. 2008Sokolova, E., Hawthorne, F. C. (2008) The Crystal Chemistry of the Scapolite-Group Minerals. i. Crystal Structure and Long-Range Order. The Canadian Mineralogist, 46 (6) 1527-1554 doi:10.3749/canmin.46.6.1527 DOI: 10.3749/canmin.46.6.1527
  5. 2021(2021) Silvialite. Handbook of Mineralogy. Mineralogical Society of America
