Souzalite

Mg3Al4(PO4)4(OH)6 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sou
Discovered
1947
Also known as
  • Souzaliet
  • Souzalit

Where it forms, where it's found

Geological setting

Rare hydrothermal alteration product of scorzalite in complex zoned granite pegmatites.

Sedimentary phosphate nodules, and in a high-pressure kyanite deposit.

Type locality
Córrego Frio mine
  1. Linópolis
  2. Divino das Laranjeiras
  3. Minas Gerais
  4. Brazil

-18.6694°, -41.4704°

15recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Blue-green · dark gray-green
Streak
Pale green
Cleavage
Distinct/Good

Two directions at approximate right angles. One good {001) and one fair perpendicular to (001). Sturman et al. (1981) write that they could find only one poor cleavage parallel to (001). However, the mineral breaks along the composition planes of the

Density
3.087 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 66 – 68° · 2V calc = 66 – 68°
Refractive index
1.617 – 1.653
Surface relief
Moderate
Principal indices
nα 1.617 – 1.618 · nβ 1.642 · nγ 1.652 – 1.653
Pleochroism
Strong

X perpendicular to cleavage = Green Y = Blue Z = elongation to Yellow

Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 7.2223 Å · b = 11.7801 Å · c = 5.1169 Å
Cell angles
α = 90.158 ° · β = 109.938 ° · γ = 81.330 °
Ratio a:b:c
1 : 1.631 : 0.708
Z
1
Morphology

Crystals are bladed, to 1 cm, in aggregates; as coarse fibrous masses.

Twinning

Polysynthetic twinning with the composition plane parallel to the good cleavage direction.

Type-locality form

Irregular, fibrous masses intimately associated with scorzalite.

Comment

boundary between souzalite (Mg dominant) and gormanite (Fe2+ dominant)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
54.95%
15PPhosphorusPhosphorus430.974123.896
17.73%
13AlAluminiumAluminium426.982107.928
15.45%
12MgMagnesiumMagnesium324.30572.915
10.43%
1HHydrogenHydrogen101.00810.080
1.44%
Total698.795100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Souzaliet
  • Souzalit

In other languages

German
Souzalith
Italian
Souzalite

Classification

Strunz
10th ed.

8.DC.45

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.45SouzaliteSpecies
Dana
8th ed.

42.09.02.01

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.09(AB)7(XO4)4Zq·xH2OType
  • 42.09.02Souzalite GroupGroup
  • 42.09.02.01SouzaliteSpecies
CIM

19.14.31

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.31SouzaliteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1948American Mineralogist (1948): 33: 205 (Proceedings of the 28 Annual Meeting).
  2. 1949Pecora, William T., Fahey, Joseph J. (1949) The Corrego Frio pegmatite, Minas Gerais: scorzalite and souzalite, two new phosphate minerals. American Mineralogist, 34 (1-2) 83-93
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1981Sturman, B. D., Mandarino, J. A., Mrose, M. E., Dunn, P. J. (1981) Gormanite, Fe2+3Al4(PO4)4(OH)6·2H2O, the ferrous analogue of souzalite, and new data for souzalite. The Canadian Mineralogist, 19 (3) 381-387
  5. 2003Le Bail, Armel, Stephens, Peter W., Hubert, Francis (2003) A crystal structure for the souzalite/gormanite series from synchrotron powder diffraction data. European Journal of Mineralogy, 15 (4) 719-723 doi:10.1127/0935-1221/2003/0015-0719DOI: 10.1127/0935-1221/2003/0015-0719
