Symesite

Pb10(SO4)O7Cl4 · H2O
IMA status
  • Approved
IMA symbol
Sy
Discovered
1998
IMA approved
1998
Also known as
  • IMA1998-035
  • Symesiet

Where it forms, where it's found

Geological setting

Oxidised zone of Mn-Pb-Cu deposit.

Type locality
Torr Works Quarry
  1. Cranmore
  2. Mendip
  3. Somerset
  4. England
  5. UK

51.1998°, -2.4379°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Translucent
Colour
Pink
Streak
White
Cleavage
Perfect
Density
7.3 g/cm³

Optical

Optical type
Biaxial
Refractive index
2.12 – 2.16
Surface relief
Very high
Principal indices
nα 2.12 · nγ 2.16
Dispersion
r < v
Optical colour
grey
Anisotropism
weak anisotropy in crossed polars
Tropism
Anisotropic
Reflectance R%
(17.20, 17.95, 5.07, 5.65) 400, (16.50, 17.40, 4.69, 5.28) 420, (15.90, 16.90, 4.40, 4.99) 440, (15.50, 16.50, 4.17, 4.77) 460, (15.20, 16.30, 4.07, 4.67) 470, (15.10, 16.10, 3.98, 4.58) 480, (14.90, 15.80, 3.83, 4.43) 500, (14.50, 15.50, 3.70, 4.30) 520, (14.30, 15.30, 3.61, 4.19) 540, (14.20, 15.30, 3.59, 4.17) 546, (14.10, 15.20, 3.53, 4.11) 560, (14.00, 15.00, 3.47, 4.05) 580, (13.90, 15.00, 3.44, 4.02) 589, (13.90, 14.90, 3.43, 3.99) 600, (13.80, 14.80, 3.39, 3.96) 620, (13.80, 14.80, 3.37, 3.93) 640, (13.70, 14.70, 3.34, 3.90) 660, (13.60, 14.65, 3.32, 3.88) 680, (13.60, 14.60, 3.30, 3.86) 700,
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 8.821(6) Å · b = 10.776(6) Å · c = 13.134(7) Å
Cell angles
α = 68.96(4) ° · β = 86.52(5) ° · γ = 75.65(4) °
Ratio a:b:c
1 : 1.222 : 1.489
Unit cell volume
1128.4 ų
Z
2
Morphology

Aggregates of blocky crystals.

Comment

Welch et al. (2000) use non-standard setting: space group B-1, with a = 19.727(2), b = 8.796(1), c = 13.631(2) Å, alpha = 82.21(1), beta = 78.08(1), gamma = 100.04(1)°, V = 2242.4(5) Å3, Z = 4. P > B transformation matrix is [0-1-1|100|01-1]

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead10207.2002072.000
84.92%
8OOxygenOxygen1215.999191.988
7.87%
17ClChlorineChlorine435.450141.800
5.81%
16SSulfurSulfur132.06032.060
1.32%
1HHydrogenHydrogen21.0082.016
0.08%
Total2439.864100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-035
  • Symesiet

In other languages

German
IMA 1998-035 · Symesit
Italian
Symesite

Classification

Strunz
10th ed.

3.DC.60

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.60SymesiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2000Welch, Mark D., Cooper, Mark A., Hawthorne, Frank C., Criddle, Alan J. (2000) Symesite, Pb10(SO4)O7Cl4(H2O), a new PbO-related sheet mineral: Description and crystal structure. American Mineralogist, 85 (10) 1526-1533 doi:10.2138/am-2000-1026 DOI: 10.2138/am-2000-1026
  2. 2009Krivovichev, S. V., Turner, R., RumseY, M., Siidra, O. I., Kirk, C. A. (2009) The crystal structure and chemistry of mereheadite. Mineralogical Magazine, 73 (1) 103-117 doi:10.1180/minmag.2009.073.1.103 DOI: 10.1180/minmag.2009.073.1.103
  3. 2011(2011) Symesite. Handbook of Mineralogy. Mineralogical Society of America
