Nadorite

PbSb3+O2Cl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Nad
Discovered
1870
Also known as
  • Ochrolite
  • Ochrolith

Where it forms, where it's found

Type locality
Nador N'Bails Mine
  1. Djebel Nador
  2. Hammam N'Bails District
  3. Guelma Province
  4. Algeria

36.3222°, 7.6417°

21recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Resinous · adamantine
Transparency
Translucent
Colour
Brown · yellow to brownish yellow
Streak
White, yellow to yellowish white
Cleavage
Perfect

On (010), perfect.

Density
7.02 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85° · 2V calc = 88°
Refractive index
2.3 – 2.4
Surface relief
Very high
Principal indices
nα 2.3 · nβ 2.34 – 2.35 · nγ 2.36 – 2.4
Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#50
Cell parameters
a = 5.603 Å · b = 12.245 Å · c = 5.448 Å
Ratio a:b:c
1 : 2.185 : 0.972
Z
4
Morphology

Crystals tabular (010), or elongated [100], also lenticular [010] with a square or octagonal outline. May be subparallel or divergent platy groups.

Twinning

On (101), nearly perpendicular (91°45'), common.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
52.27%
51SbAntimonyAntimony1121.760121.760
30.72%
17ClChlorineChlorine135.45035.450
8.94%
8OOxygenOxygen215.99931.998
8.07%
Total396.408100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ochrolite
  • Ochrolith

In other languages

French
Nadorite
German
Nadorit
Spanish
Nadorita
Italian
Nadorite
Arabic
ناظوريت

Classification

Strunz
10th ed.

3.DC.30

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DCWith Pb (As,Sb,Bi), without CuGroup
  • 3.DC.30NadoriteSpecies
Dana
8th ed.

10.02.05.02

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.02A(O,OH)XqType
  • 10.02.05Perite SeriesGroup
  • 10.02.05.02NadoriteSpecies
CIM

24.3.4

  • 24Antimonates and AntimonitesClass
  • 24.3Antimonates of Ti and PbGroup
  • 24.3.4NadoriteSpecies

Group, growth & confusion

In the same group
2 members
Often grow together
10 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1870Flajolot, M (1870); Comptes rendus de l’Académie des sciences de Paris, 71, 237.
  2. 1888Cesàro (1888) Bulletin de la Société française de Minéralogie: 11: 44.
  3. 1889Flink (1889) Ak. Stockholm, Öfversigy: 46: 5 (as Ochrolith).
  4. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  5. 1920(1920) Atlas Der Krystallformen Vol. 6 - Text - Band VI - Markasit-Pyrit. Carl Winters Universitätsbuchhandlung, Heidelberg.
