Terlinguaite

Hg2OCl
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tlg
Discovered
1900
Also known as
  • Terlinguaiet

Where it forms, where it's found

Geological setting

Secondary mineral in a hydrothermal mercury deposit.

Type locality
Terlingua Mining District
  1. Texas
  2. USA
21recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellow- · yellow-green · brown (darkens to olive-green on exposure to light) · pale olive-green in transmitted light
Streak
Lemon yellow
Tenacity
brittle
Cleavage
Perfect

On (101)

Density
8.725 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20° · 2V calc = 26°
Refractive index
2.35 – 2.66
Surface relief
Very high
Principal indices
nα 2.35 · nβ 2.64 · nγ 2.66
Pleochroism
Weak

Slightly pleochroic in green and yellow.

Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.3100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]3100 nm6th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation3100 nm
Order6th order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#11
Cell parameters
a = 19.51 Å · b = 5.91 Å · c = 9.47 Å
Cell angles
β = 143.81 °
Ratio a:b:c
1 : 0.303 : 0.485
Z
4
Morphology

Crystals prismatic [010] and often somewhat flattened on (001); rarely prismatic in a pyramidal direction; also equidimensional, or thick tabular (001). Pulverulent; massive aggregates of imperfect crystals (Dana, 7th. ed.: 53).

Type-locality form

Agglomeration of imperfect striated, bright yellow crystals. Less frequently as doubly terminated crystals to 1 mm in length.

Comment

C2/c (synthetic).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
80HgMercuryMercury2200.592401.184
88.63%
17ClChlorineChlorine135.45035.450
7.83%
8OOxygenOxygen115.99915.999
3.54%
Total452.633100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Terlinguaiet

In other languages

French
Terlinguaïte
German
Terlinguait
Italian
Terlinguaite
Russian
Терлингуаит

Classification

Strunz
10th ed.

3.DD.20

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DDWith HgGroup
  • 3.DD.20TerlinguaiteSpecies
Dana
8th ed.

10.04.02.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.04A2(O,OH)XqType
  • 10.04.02Terlinguaite GroupGroup
  • 10.04.02.01TerlinguaiteSpecies
CIM

8.5.3

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.5Halides of Zn and HgGroup
  • 8.5.3TerlinguaiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1900Turner, W.H. (1900) Terlinguaite. in The Terlingua Mining District, Brewster Co., Texas, Mining and Scientific Press (San Francisco): 21 July 1900.
  2. 1903Moses, A.J. (1903) Eglestonite, terlinguaite, and montroydite, new mercury minerals from Terlingua, Texas. American Journal of Science: 16: 253-263.
  3. 1904Moses, A. J. (1904) Eglestonit, Terlinguaït und Montroydit, neue Quecksilbermineralien von Terlingua in Texas. Zeitschrift für Kristallographie, 39 (1). 3-13 doi:10.1524/zkri.1904.39.1.3DOI: 10.1524/zkri.1904.39.1.3
  4. 1906Turner, Henry Ward (1906) The Terlingua quicksilver deposits. Economic Geology, 1 (3). 265-281 doi:10.2113/gsecongeo.1.3.265DOI: 10.2113/gsecongeo.1.3.265
  5. 1909Hillebrand, W.F.; Schaller, W.T. (1909) The mercury minerals from Terlingua, Texas. Bulletin 405. US Geological Survey p.1-174. doi:10.3133/b405 DOI: 10.3133/b405
