Tinaksite

K2NaCa2TiSi7O18(OH)O
IMA status
  • Approved
IMA symbol
Tnk
Discovered
1965
Also known as
  • Tinaksiet

Where it forms, where it's found

Geological setting

K-feldspar metasomatites at the contact of the massif with limestones.

Type locality
Murunskii Massif
  1. Chara and Tokko Rivers Confluence
  2. Aldan Shield
  3. Russia
3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellowish · grayish-white
Cleavage
Perfect

Perfect on (010), imperfect on (110); (010) ∧ (110) = 131.5°.

Density
2.82 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.593 – 1.666
Surface relief
Moderate
Principal indices
nα 1.593 · nβ 1.621 · nγ 1.666
Dispersion
none
Extinction
X' ∧ {010} = 1°-4°; Y ∧ {010} = 16°-18°.
Michel-Lévy diagramhighlighted lineδ = 0.0730
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]730 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation730 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 10.37 Å · b = 12.16 Å · c = 7.05 Å
Cell angles
α = 90.91 ° · β = 99.31 ° · γ = 92.76 °
Ratio a:b:c
1 : 1.173 : 0.680
Type-locality form

Well-bounded prismatic crystals from tenths of a mm to several cm, often grouped in radiating fibrous aggregates and rosettes up to 3-5 cm in diameter.

Comment

Mean parameters concerning the structure refinement (Lacalamita et al., 2016): a~10.373, b~12.176, c~7.057, α~90.82, β~99.22, γ~92.80, V~878.5

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
42.85%
14SiSiliconSilicon728.085196.595
26.33%
20CaCalciumCalcium240.07880.156
10.73%
19KPotassiumPotassium239.09878.196
10.47%
22TiTitaniumTitanium147.86747.867
6.41%
11NaSodiumSodium122.99022.990
3.08%
1HHydrogenHydrogen11.0081.008
0.13%
Total746.792100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • H2O

Synonyms

  • Tinaksiet

In other languages

French
Tinaksite
German
Tinaksit
Italian
Tinaksite
Chinese
矽鈦鈣鉀石
Russian
Тинаксит

Classification

Strunz
10th ed.

9.DG.75

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.75TinaksiteSpecies
Dana
8th ed.

67.02.01.01

  • 67Inosilicates Unbranched Chains with W > 2Class
  • 67.02Unbranched Chains with W>2 with W=5Type
  • 67.02.01Tinaksite groupGroup
  • 67.02.01.01TinaksiteSpecies
CIM

14.9.36

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.36TinaksiteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. Mineralogicheskii Zhurnal, Kiev: 13(4): 3-12.
  2. 1965Fleischer, Michael (1965) New Mineral Names. American Mineralogist, 50 (11-12) 2096-2111
  3. 1965Rogov, Y.G., Rogova, V.P., Voronkov, A.A., Moleva, V.A. (1965) Tinaksite NaK2Ca2TiSi7O19(OH), a new mineral. Doklady Akademii Nauk SSSR, 162, 658-661.
  4. 1980Bissert, G. (1980) Verfeinerung der Struktur von Tinaksit, Ca2K2NaTiO[Si7O18(OH)]. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 36 (2) 259-263 doi:10.1107/s0567740880003068DOI: 10.1107/s0567740880003068
  5. 1989Rozhdestvenskaya, I. V.; Nikishova, L. V.; Lazebnik, Yu. D.; Lazebnik, K. A. (1989) The crystal structure of tokkoite and its relation to the structure of tinaksite. Zeitschrift für Kristallographie, 189 (3-4). 195-204 doi:10.1524/zkri.1989.189.3-4.195 DOI: 10.1524/zkri.1989.189.3-4.195
